Zotek ZTX [8/26] ⑭ analog bar graph
![Zotek ZTX [8/26] ⑭ analog bar graph](/views2/1893222/page8/bg8.png)
4
⑪
Frequency
test. (Hertz)
⑫
Temperature
test. (Celsius)
⑬
Temperature
test. (Fahrenheit)
⑭
Analog
bar graph.
⑮
Resistance
test. (Ohm)
⑯
Current
test. (Ampere)
⑰
Voltage
test. (Volt)
⑱
Primary
measurement display.
⑲
The
product measures
both
sinusoidal
and nonsinusoidal
ac
waveforms
accurately.
⑳
Low
battery. Replace batteries.
㉑
Negative
readings.
㉒
Alternating
current.
㉓
Direct
current.
㉔
Display
freezes present reading.
Measurement
units.
