VTS VENTUS PRO PVS PO 30 AC [11/25] General features
![VTS VENTUS PRO PVS PO 30 EC [11/25] General features](/views2/1893542/page11/bgb.png)
HYGIENIC AIR HANDLING UNIT GENERAL FEATURES
» Devices delivered in Plug & Play standard. With built-in power and control circuit (MCC & DDC).
» All of the components are in a structure that does not allow the formation of a microbiological environment.
» All connections and dampers are leakproof and of a standard to prevent condensation.
» The panels are designed to minimize condensation (T2-TB2).
» Internal surfaces are designed with stainless (304SS & 316SS) antibacterial structure without any
indentation or protrusion. It does not accumulate dirt and dust.
» It has a structure that prevents uninterrupted and water accumulation with the correct drainage design.
» It is produced in a way that the hygiene structure will not deteriorate during the transportation
and commissioning phase.
EN 1886 VDI 6022 VDI 3803 DIN 1946 EN 13053
Hygienic air handling units can be also prodused with
different designs and components.
Technical Specification Technical Specification
2322
VTS Group hygienic air handling units are special devices designed to be used in hospital and clean
room applications that require sensitive and sterile conditions. It can be used in operating theaters,
clean rooms, pharmaceutical and chemical industry, food industry and special industrial applications
where hygiene conditions are required. Hygienic air handling units are used in the health and food
sector to prevent bacterias and viruses from entering the sterile environment, to create clean air
that the environment needs, and to provide a positive and negative pressure balance suitable for
the purpose of the sterile environment.
AHU N° 22.05.007
Range: VENTUS PRO PVS
