CERTIFICATIONS
VENTUS PRO - PVS SERIES AIR HANDLING UNITS
VTS Group air handling units meet all the comfort needs of every building with its custome design
and high exibility. Production is carried out in accordance with EN 1886 and EN13053 standards
in production facilities holding ISO-9001, ISO-14001 and OHSAS-18001 certicates.
VENTUS PRO - PVS series air handling units have been approved by Eurovent.
The casing of the VENTUS PRO - PVS AHUs is made of a steel or aluminum frame, to which "sandwich"
panels made of rock wool, covered with a metal sheet on both sides, are attached. Air Handling Units
are available in 71 sizes covering a ow range from 1 000 – 125 000 m³/h. A wide range of options
and accessories are available. Units are manufactured in modular sections, which are easy to handling
and installation.
» 1 000 – 125 000 m³/h air ow
» 60 mm standart panel thickness
» 0,8 mm % 1,0 mm sheet thickness
» Galvanized, stainless, epoxy inner & outside sheet
» Steel & aluminum prole
» Different & special production options
QUALITY AND STANDARTS
VENTUS PRO - PVS series air handling units optimize the indoor air quality by controlling the temperature
and humidity. With exible and environmentally friendly performance, it provides high energy savings
as well as comfort.
» 71 sizes in total
» Flexible and multidirectional production options
» High quality and efcieny
» Eurovent approved performance guarantee
» Designed in accordance with EN 1886 and EN 13053 standards
Brand Range
Heat Transfer
Calss
Thermal Bridge
Factor
Filter Bypass
Leakage
Casing Tightness
-400 / + 700 pa
Mechanical
Strength Class of
the Casing
VTS VENTUS PRO - PVS T2 TB2 F9 L1 D1
MECHANICAL PERFORMANCES ACCORDING TO EN1886 NORMS
CASING ACCOUSTICAL PERFORMANCES
* Performance values certied by Eurovent
* Performance values certied by Eurovent
HZ 125 250 500 1000 2000 4000 8000
dB 14 28 26 31 22 27 42
1/2
EUROVENT CERTITA CERTIFICATION SAS au capital de 100 000 € - 48-50 rue de la Victoire 75009 Paris - FRANCE
Tel. : 33 (0)1 75 44 71 71 - 513 133 637 RCS Paris - SIRET 513 133 637 000 35 - TVA FR 59513133637
S06D06 TEMPLATE_ECP_RANGE_REV1.1
CERTIFICATE
N° 22.05.007
Air Handling Unit / Centrales de traitement d'air
Range Name / Nom de Gamme :
VENTUS PRO PVS
Granted on May 10, 2022 -
Date 1ère admission 10 mai 2022
This document is valid at the date of issue -
Check the current validity on:
Document valable à la date d’émission
-
Vérifier la validité en cours sur :
www.eurovent-certification.com
Participant/Titulaire
VTS sp. z o.o.
Al. Grunwaldzka 472
A 80-309 Gdansk, Poland
This product performance certificate is issued by
Eurovent Certita Certification according to the
certification rules:
ECP AHU - « Air Handling Unit » in force at
established date.
Pursuant to the decision notified by Eurovent Certita
Certification, the right to use the mark ECP shall be
granted to the beneficiary company for the above Range
in the conditions defined by the certification program
mentioned.
Unless withdrawn or suspended, this certificate remains
valid as long as the requirements for the certification
program framework are met. The validity of the
certificate is to be verified on www.eurovent-
certification.com
THIS CERTIFICATE HAS BEEN ISSUED ON 10/05/2022
THIS CERTIFICATE IS VALID UNTIL 30/11/2022
Ce certificat de performance produit est délivré par Eurovent
Certita Certification
dans les conditions fixées par le
référentiel :
ECP AHU – « Centrales de traitement d'air » en vigueur à
date d’édition.
En vertu de la décision notifiée par Eurovent Certita
Certification, le droit d'usage de la marque ECP, est accordé à
la société qui en est bénéficiaire pour la gamme visée ci-
dessus, dans les conditions définies par le programme de
certification mentionné.
Sauf retrait ou suspension, ce certificat demeure valide tant
que les conditions du référentiel du programme de certification
sont respectées. La validité du certificat est à vérifier sur le site
Internet www.eurovent-certification.com
CE CERTIFICAT A ÉTÉ EMIS LE 10/05/2022
CE CERTIFICAT EST VALIDE JUSQU’AU 30/11/2022
Paris, 10 mai 2022
MANAGING BOARD MEMBER / MEMBRE DIRECTOIRE
Organisme accrédité n° 5-0517
Certification Produits et Services selon la
norme NF EN ISO/CEI 17065:2012
Portée disponible sur www.cofrac.fr
Accreditation #5-0517 Products and
Services Certification according to NF EN
ISO/CEI 17065:2012 –
Scope available on www.cofrac.fr
COFRAC est signataire des accords MLA
d’EA et MLA d’IAF,
COFRAC is signatory of EA MLA and IAF
MLA,
list of EA members is available on
www.european-accreditation.org/ea-members
list of IAF members is available on
www.iaf.nu//articles/IAF_MEMBERS_SIGNATORIES/4
