Ventus Air Handling Units
Table 6. Types of the supply and drainage connection
AHU size
VVS 21 - 55
VVS 75 - 650
Humidifier type
Direct drain
Circulating
Supply connection
DN15 threaded
galvanized pipe
High pressure nylon
hose Ø10mm
Drainage connection
DN25 threaded
galvanized pipe
DN25 threaded
galvanized pipe
L/R side versions
no, universal
yes
Table 7a. Parameters of humidifier
Parameter
Limit values
Critical air velocity VVS21-55
3.0m/s
Critical air velocity VVS75-650
4.0m/s
Water temperature
5..40°C
Water pressure
0,15..0,75MPa
Feed water quality
tap water
Ambient temperature for electric cabinet
5..50°C
Ambient humidity for electric cabinet, max
90%rH
Table 7b. Recommended water quality parameters
Parametr
Zawartość w wodzie zasilającej
Temperatura
< 20 °C
Aluminium
< 200 μg/l
Amon <
< 0.50 mg/l
Wapń
< 300 mg/l
Chlorek
< 300 mg/l
Miedź
< 1 mg/l
Przewodność
< 2000 μS/cm w 20°C (
pH 6,5 do 9,5
6.5 to 9.5
Żelazo <0,5 mg / l
< 0.5 mg/l
Mangan <0,1 mg / l
< 0.1 mg/l
Zapach
Akceptowalny dla użytkowników
Siarczan
< 250 mg/l
Krzemian
< 150 mg/l
Trihalometan
< 100 μg/l
Liczba kolonii w 22 ° C
< 100/ml
Bakterie z grupy coli
0/100 ml
Bakterie Legionella
< 50 cfu/1000 ml
Gatunek Pseudomonas
0/250 ml
Direct drain humidifier is simplified compact construction for limited space in the AHU. Supply water
feeds the humidifying pad from the top and the excessive water falls to the draining pan and goes
directly out of the AHU.
Water supply is controlled by means of solenoid valve installed in the control cabinet (included in the
delivery).
Circulating humidifier relies on the circulating pump which sits in water tank and feeds water to the
humidifying pad. Excessive water falls to the tank and is used again to feed the pad. Due to
evaporation, water level decreases and activates the floating valve, which controls the water supply.
