4.11.4 Fan’s motor
VVS 21-30 with motor power till 0,75kW
Ahus are equipped with the fans with the modern and high-performance EC motors. IP protection
class of the motors with the controller is 44. The own electronics of the protect them against the
overload, phase fail/lose, under and over voltage and phase over current.
The motor can be started by means of digital commands, bus commands, references or local start
command whenever the drive is connected to the AC line.
From the motor are leads cables ended with molex (Fig.21).
VVS 21-30 with motor higher than 0,75kW and VVS 40-650 AHUs
Fans' motors are adapted to operation in dusty and humid environment (IP55) and their insulation (F-
class) is adapted to cooperation with the frequency converter. No additional means inuring the motor
against conditions of the AHU fans' section are required.
Motors used in our AHUs are by default motors with their own cooling system and with fans built into
a shaft. Supply cabling must be led to the fan's motor via rubber passes located in the back panel of
the AHU casing.
Caution! This is not permissible to lead supply wiring through the inspection panel
Intermediate fan drive
Fans' motors with belt drive are powered by 3x400V/50Hz voltage. The connection should be done
through the overload and short-circuit protection suitable for rated current of the motor.
Attention: Fan motors with the power of 4kW can be started directly. Motors with the
power of 5.5 kW and more should be started in a ‚star - triangle’ start-up system.
Direct fan drive
Direct driven fan EC motors are powered with 1x230V single-phase voltage. AC motors with power
up to 2.2 kW are powered with 3x230V voltage from frequency converters powered with 1x230V
single-phase voltage. Motors with higher powers are powered with 3x400V voltage with the
cooperation with frequency converters powered by 3x400V three-phase system.
Attention: before connecting the fan set one should check carefully the rated
parameters of both power supply and the converter’s output.
One should connect the fan set by means of fault protection appropriate for the applied frequency
converter. In the case of use EC motors or AC motors powering with the use of a converter it is not
necessary to connect the motor’s PTC protection.
Overload protection is realized on the frequency converter by means of activating specified
parameters and introducing the motor’s rated data in accordance with the manual provided together
with the frequency converter.
Attention: In fan sections equipped with more than one fan synchronous operation of
fans should be ensured.
The fan control system should be prepared in such a way so as to provide
simultaneous start- up, rotary speed control and stoppage.
In case of a breakdown and stoppage of one fan the fan set does not fulfil its function
and should be disabled.
Attention! In the inspection door of the fan section is installed limit switch, which cause
the fan to stop in case of unauthorized opening of the door. The switch must be
connected to the frequency converter, accordance with the wiring diagram attached in
the separate manual: "Control and Modbus communication - appendix to the manual of
LG iC5 and iG5A frequency converters".
In case of powering the motor from a frequency converter, high-frequency currents or voltage
harmonic components in wiring powering the motor can generate some electromagnetic
interferences. Connection between the frequency converter and motor should be done using
shielded cables, in accordance with guidelines outlined in the operation and maintenance manual of
the frequency converter.
