Ventus Air Handling Units
Technical information to the regulation (EU) No 327/2011 implementing Directive 2009/125/EC
Model:
35/3/2
40/1,5/4
40/2,2/4
40/3/4
45/2,2/4
45/4/4
45/5,5/4
50/4/4
50/5,5/4
VVSD10
VVSD10
VVSD10
VVSD10
VVSD10
VVSD10
VVSD10
VVSD10
VVSD10
+55 °C
+55 °C
+55 °C
+55 °C
+55 °C
+55 °C
+55 °C
+55 °C
+55 °C
1.
60,70%
61,60%
62,20%
60,10%
60,90%
63,60%
64,70%
62,70%
63,80%
2.
A
3.
Static
4.
62
5.
VSD - yes. A variable speed drive must be installed with this fan.
6.
2020
7.
ALLTS Sp. z o.o., CRN 0000236306, Poland
8.
1-2-0208-
0008
1-2-0209-
0008
1-2-0209-
0006
1-2-0209-
0007
1-2-0211-
0008
1-2-0211-
0006
1-2-0211-
0007
1-2-0212-
0006
1-2-0212-
0007
2,41kW,
0,29kW,
0,48kW,
3,26kW,
0,89kW,
0,89kW,
0,9kW,
1,58kW,
1,6kW,
9.
4300m³/h,
1910m³/h,
2500m³/h,
5600m³/h,
4000m³/h,
4100m³/h,
4000m³/h,
5900m³/h,
5775m³/h,
1156Pa
300Pa
388Pa
1200Pa
448Pa
456Pa
481Pa
564Pa
594Pa
10.
2835RPM
1420RPM
1420RPM
2673RPM
1420RPM
1440RPM
1455RPM
1440RPM
1455RPM
11.
1
Disassembly of the machine must be carried out and/or supervised by qualified personnel with appropriate
expert knowledge.
Contact a certified waste disposal organization in your vicinity. Clarify what is expected in terms of the quality
of dismantling the machine and provision of the components.
Dismantle the machine using the general procedures commonly used in mechanical engineering.
WARNING
Machine parts can fall The machine is made up of heavy parts. These parts are liable to fall during
dismantling. This can result in death, serious injury, or material damage.
Follow the safety rules:
1. Disconnect all electrical connections.
2. Prevent reconnection.
3. Make sure that the equipment is at zero voltage.
12.
4. Cover or isolate nearby components that are still live.
To energize the system, apply the measures in reverse order.
Components:
The machines consist for the most part of steel and various proportions of copper, aluminum and plastics
(impeller made of SAN - styrene, acrylonitryle, construction material with 20% glass fiber). Metals are
generally considered to be unlimitedly recyclable.
Sort the components for recycling according to whether they are:
Iron and steel, aluminum, non-ferrous metal, e.g. windings (the winding insulation is incinerated during
copper recycling), insulating materials, cables and wires, electronic waste, plastic parts (impeller, winding
cover ect.). The same goes for cloths and cleaning substances which have been used while working on the
machine.
Dispose of the separated components according to local regulations or via a specialist disposal company.
13.
Long failure-free operation depends on keeping the product/device/fan within performance limitations
described by selection software or maintenance manual.
For proper operation, read carefully maintenance manual, with special attention on “installation”, “start-up”,
and “maintenance” chapters.
14.
no additional elements
