31
VTS reserves the right to implement changes without prior notice
Ventus Air Handling Units
Before putting into service and after long time of storage or standstill, the resistance of insulation
between the casing and winding should be determined, applying direct current.
Minimal value of insulation resistance for a new, renewed or repaired winding should be 10 MΩ in
relation to the ground.
Fig.18. Connecting power cables and clamps in a cable box of one-speed motors
Converter power supply
1x230V/50Hz
Converter power supply
3x400V/50Hz
Supplying power to the motor through frequency converter
Motor power supply
3x400V/50Hz
Marking on the engine
rating plate
