NVS 80 Code
W
[mm]
W
i
[mm]
H
[mm]
H
i
[mm]
L
[mm]
M
[kg]
Fan section (ventilation) NVS 80 V 940 860 689 609 757 76
Fan section with water cooling coil
(3-row exchanger)
NVS 80 WC3.V 940 860 689 609 1 122 113
Fan section with direct expansion cooler (3-
row mono-section exchanger)
NVS 80 DX3.1.V 940 860 689 609 1 122 113
Ducted water heating coil
(3-row exchanger)
NVS 80 WH3 920 860 673 603 140 17
Ducted water heating coil
(2-row exchanger)
NVS 80 WH2 920 860 673 603 85 15
Ducted electric heater (72 kW) NVS 80 EH72 920 860 673 609 246 11
Ducted at lter (EU4) NVS 80 PG4 920 860 673 609 132 8
Ducted bag lter (EU5) NVS 80 BF5 920 860 673 609 342 16
Ducted bag lter (EU7) NVS 80 BF7 920 860 673 609 642 25
Set of noise attenuator panels (x2 pcs)* NVS 80 S 860 608 19
NVS 65 Code
W
[mm]
W
i
[mm]
H
[mm]
H
i
[mm]
L
[mm]
M
[kg]
Fan section (ventilation) NVS 65 V 820 740 593 513 757 52
Fan section with water cooling coil
(3-row exchanger)
NVS 65 WC3.V 820 740 593 513 1 122 81
Fan section with direct expansion cooler (3-
row mono-section exchanger)
NVS 65 DX3.1.V 820 740 593 513 1 122 81
Ducted water heating coil
(3-row exchanger)
NVS 65 WH3 800 740 573 508 140 13
Ducted water heating coil
(2-row exchanger)
NVS 65 WH2 800 740 573 508 85 11
Ducted electric heater (54 kW) NVS 65 EH54 800 740 573 513 246 11
Ducted at lter (EU4) NVS 65 PG4 800 740 573 513 132 7
Ducted bag lter (EU5) NVS 65 BF5 800 740 573 513 342 14
Ducted bag lter (EU7) NVS 65 BF7 800 740 573 513 642 22
Set of noise attenuator panels (x2 pcs)* NVS 65 S 740 508 1 000 17
The base sections of the N-TYPE range
are thermally secured by casing manu-
factured using Monocoque technology.
Fan set.
Fan set with water coil cooler.
Fan set with direct expansion cooler.
FUNCTION AND APPLICATION:
Room ventilation.
Forced air circulation in supply
and exhaust systems.
CASING PANELS:
PPU density: 42 kg/m³.
Panel weight: 10 kg/m².
CONSTRUCTION:
The housing of the section has a light,
rigid and durable frameless construction.
CONSTRUCTION
OF THE SECTIONS
Size
Type of
electric motor
Rated power Rated speed Rated voltage Current
[kW] [1/min] [V] [A]
NVS 23 71M-0.55/2p 0.55 2800 3~230 V / 3~400 V 2.4 / 1.4
NVS 39 80M-1.1/2p 1.10 2845 3~230 V / 3~400 V 4.2 / 2.40
NVS 65 90L-2.2/2p 2.20 2880 3~230 V / 3~400 V 7.9 / 4.55
NVS 80 112M-4/2p 4.00 2905 3~400 V / 3~690 V 7.8 / 4.5
Fan sets are equipped with highly
efcient plug fans with a direct drive.
The impeller’s blades are backward-
curved. The fan’s design allows for the
smooth and efcient regulation of the air
ow rate.Fan sets are equipped
with highly efcient plug fans
with a direct drive. The impeller’s
blades are backward-curved.
The prole of the impeller
is aerodynamic helping to reduce
friction-related pressure losses
and excessive noise.
The prole of the impeller
is aerodynamic helping to reduce
friction-related pressure losses
and excessive noise.
FAN SECTION (VENTILATION)
The impeller is made
of a styrene/acrylonitrile polymer with
glass bre. The impeller is made
of material ensuring a long service life and
high resistance to air contamination.
Three-phase asynchronous
electric motors:
- rated voltage:
3 x 240 V / 3 x 400 V AC,
- motor winding insulation class:
F (mated to an inverter),
- bearing life:
L
10
= 20000 h / L
50
= 100000 h,
- protection rating: IP55,
- working environment: 60°C.
H
i
H
W
i
W
L
* panel length 1000 mm, width 140 mm
W - outer width
W
i
- internal cross section width (air ow slot)
H - outer height
H
i
- internal cross section width (air ow slot)
L - length
M - weight
The casing is made of 40 mm thick
panels, made of polyurethane foam
(PUR-40) and two galvanized sheets
(S280GD + Z180). The external surface
of the casing panel is additionally protected
with a 25 μm thick organic coating.
FAN SETS
DIMENSIONS OF THE SECTIONS
AND FUNCTIONAL ELEMENTS
Three-phase motor ratings
Size
Type of
electric motor
Rated power Rated speed Rated voltage Current
[kW] [1/min]7 [V] [A]
NVS 23 71M-0.37/2p 0.37 2820 1~230 V 2.70
NVS 39 80M-1.1/2p 1.1 2780 1~230 V 7.00
NVS 65 90L-2.0/2p 2.0 2780 1~230 V 13.00
Single-phase motor ratings
10
11
