The noise attenuation function
is an optional element of the air
handling unit’s equipment.
The noise attenuation panels
are 140 mm thick and 1000 mm long.
FUNCTIONS AND APPLICATION:
Reduction of sound power level.
The internal lling of the noise
attenuation panel consists of sound-
absorbent and non-combustible mineral
wool with a density of 60 kg/m
3
and 80 kg/m
3
respectively.
Outer surface: thin non-woven fabric
(”veil”), which eliminates the passage
of wool particles into the ventilation
air stream.
Number of noise attenuation panels
per attenuation block:
2 (NVS 23, NVS 39);
3 (NVS 65, NVS 80).
CONSTRUCTION:
Pleated lter fabric in the steel mesh
housing installed in a 50 mm thick frame.
The lter fabric is made of polyester bre.
Installation: System of guides allows
for the quick and easy replacement
of lters.
FUNCTIONS AND APPLICATION:
Final lters for general ventilation
and air conditioning systems with
average air purity requirements.
Pre-lters for ventilation
and air conditioning systems
with high air purity requirements
installed upstream from the nal lters.
AIR FILTERS
Size 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Lw [dB]
NVS 23 10.6 16.0 26.7 32.0 34.1 34.7 33.9 40.0
NVS 39 10.0 15.0 24.9 30.0 32.0 32.5 31.8 37.9
NVS 65 9.4 14.1 23.5 28.1 30.0 30.4 29.9 36.0
NVS 80 9.0 13.5 22.4 26.9 28.7 29.1 28.6 34.7
CROSS-FLOW HEAT
RECUPERATOR
FUNCTION AND APPLICATION:
Indirect recovery of energy
(latent heat) cumulated in stream
of exhausted air and transfer of the
energy to air supplied into a room.
Energy recover with very good
isolation of supplied air stream
from exhausted air stream (99.9%).
CONSTRUCTION:
Set of transversally pressed aluminium
plates with air ows in between,
by alternate manner of cross-ow system.
Size
Airow range Max. efciency Min. efciency
Min. air face
velocity
Max. air face
velocity
Min. pressure drop
Max. pressure
drop
m
3
/h % % m/s m/s Pa Pa
min.-max. supply/exhaust supply/exhaust supply/exhaust supply/exhaust
NVS 23 700-2200 56 53 2.1 / 1.9 3.5 / 3.1 63 / 55 160 / 140
NVS 39 1700-3300 56 53 2.0 / 1.8 3.9 / 3.5 59 / 52 190 / 170
NVS 65 2600-5000 58 55 2.0 / 1.8 3.9 / 3.5 60 / 53 190 / 170
NVS 80 3400-7000 62 59 1.9 / 1.7 3.9 / 3.4 59 / 51 210 / 184
Size H [mm] L [mm] B [mm] D [mm] m [kg]
NVS 23 690 690 360 963 22
NVS 39 690 690 470 963 26
NVS 65 840 840 555 1175 38
NVS 80 990 990 650 1387 57
Ducted panel lter (P.G4)
Size
Filter
type
Filter properties
Filter dimensions
W
i
x H
i
x B
i
Frontal cross-sectional
area
Filter area
[mm] x [mm] x [mm] [m
2
] [m
2
]
NVS 23
G4
594x290x50 0,17 0.34
NVS 39 594x430x50 0,26 0.51
NVS 65 734x513x50 0,38 0.75
NVS 80 854x609x50 0,52 1.04
CONSTRUCTION:
The lter fabric is made of polyester bre.
Vertical arrangement of the lter bags.
Installation: System of guides allows
for the quick and easy replacement
of lters.
FUNCTIONS AND APPLICATION:
Final lters for general ventilation
and air conditioning systems
with average air purity requirements.
Pre-lters for ventilation and air
conditioning systems with high
air purity requirements, installed
upstream from the nal lters.
Ducted bag lter (B.F5)
Size
Filter
type
Filter properties
Filter dimensions
W
i
x H
i
x B
i
Frontal cross-sectional
area
Filter area
[mm] x [mm] x [mm] [m
2
] [m
2
]
NVS 23
F5
592x287x300 0.17 1.11
NVS 39 592x428x300 0.25 1.66
NVS 65
428x490x300
0.35 2.16
287x490x300
NVS 80
428x592x300
0.51 2.89
428x592x300
Mufer specications
NOISE ATTENUATION PANELS
Cross-ow recuperator dimensions
Cross-ow recuperator specications
Sectional lter specications
Ducted bag lter specications (B.F5)
14
15
