CONSTRUCTION:
600 mm lter bags in a 25 mm
thick frame.
The lter fabric is made
of polyester bre.
Vertical arrangement of the lter bags.
Installation: System of guides allows
for the quick and easy replacement
of the lters.
FUNCTIONS AND APPLICATION:
Final lters for ventilation and air
conditioning systems with high
air purity requirements.
Ducted bag lter (B.F7)
Size
Filter
type
Filter properties
Filter dimensions
W
i
x H
i
x B
i
Frontal cross-sectional
area
Filter area
[mm] x [mm] x [mm] [m
2
] [m
2
]
NVS 23
F7
592x287x600 0.17 3.13
NVS 39 592x428x600 0.25 4.68
NVS 65
428x490x600
0.35 6.28
287x490x600
NVS 80
428x592x600
0.51 8.66
428x592x600
FUNCTIONS AND APPLICATION:
Air ow cut-off through
the air handling unit.
Air ow adjustment through
the air handling unit.
Air mixing rate adjustment
in the supply and exhaust air
handling units.
OPTIONAL ELEMENTS
Air damper
CONSTRUCTION:
The blades are made
of constructional plastic (ASA),
with the edges protected with seals
of soft composite material.
The blades rotate in pairs
in opposing directions.
Aluminium frame.
The drive is realized by means
of composite gears installed inside
the damper’s frame.
The damper is equipped with a square
stem tted for actuator installation.
FUNCTIONS AND APPLICATION:
Protection of the ventilation system
(ducts) from vibrations transferred
from the air handling unit.
Compensation of ventilation ducts’
misalignment in relation to the axis
of the air handling unit.
Flexible connection
CONSTRUCTION:
Flange: PVC-C material
with UV stabilizer.
Ambient temperature:
from -30°C to 97°C. Fire resistance
UL 94HB [ISO 1210].
Composite material: PVC coated
polyester fabric. Ambient temperature:
from -30°C to 70°C.
Flexible connections are to be tted
with an earthing wire to balance
the electric potential.
The professional control system is offered along with the air handling units of VENTUS N-TYPE series. It ensures easy
control over ventilation and air conditioning systems and results in failure-free operation. Desired air parameters
are achieved at minimal costs. The heart of control system is integrated with HMI OPTIMA user interface. It ensures
unprecedented convenience and simplicity of air parameters adjustment.
FUNCTIONS AND APPLICATION:
Setting and reading the parameters
of the air handling unit.
Selection and conguration
of the operating mode.
Operating calendar settings.
Information on the alarm status
and possibility of its cancellation.
CONTROL SYSTEM
OPERATING PARAMETERS:
Supply voltage: 230 V AC.
Frequency: 50 Hz ± 1 Hz.
Supply voltage in the control circuits:
24 V AC.
Protection degree: IP20.
Operating environment temperature:
from 0°C to +40°C.
HMI OPTIMA - USER INTERFACE
FUNCTIONS AND APPLICATION:
Measurement of the temperature
of supply air, exhaust air or external air.
Protection of maximum
and minimum supply air temperature.
OPERATING PARAMETERS:
Measurement: from -50°C to +110°C,
Measurement accuracy: ±0,5 K.
Measuring element: PT1000,
output signal: resistance.
Communication cable length:
maximum 150 m.
Protection degree: IP67.
DUCT TEMPERATURE SENSOR
CONSTRUCTION:
Resistive measuring element installed
in the aluminium 25 cm long
bayonet probe.
Ducted bag lter specications (B.F7)
