Motor Control Diagnostic Codes
312066ZAF 13
Motor Control Diagnostic Codes
Motor control diagnostic codes E21 through E29 appear
on pressure display.
There are two types of motor control codes: alarms and
warnings. Alarms take priority over warnings.
Alarms
Alarms turn off Reactor. Turn main power OFF
then ON to clear.
NOTE: Alarms can also be cleared, except for code 23,
by pressing .
Warnings
Reactor will continue to run. Press to clear. A
warning will not recur for a predetermined amount of
time (varies for different warnings), or until main power
is turned OFF then ON .
Code Code Name Alarm (A)
or
Warning
(W)
Corrective
Action
page
21 No transducer
(component A)
A 16
22 No transducer
(component B)
A 16
23 High fluid pressure A 16
24 Pressure imbalance A/W (to
select, see
page 36)
16
25 High line voltage A 18
26 Low line voltage A 18
27 High motor
temperature
A 18
28 High current A 29
29 Brush wear W 19
30 Momentary loss of
communication
- 18
31 Motor control failure A 17
32 Motor control
overtemperature
A 18
99 Loss of communication - 18
