Graco Reactor E-20 FP9030 [35/76] Electric motor
![Graco Reactor E-20 FP9030 [35/76] Electric motor](/views2/1900107/page35/bg23.png)
Repair
312066ZAF 35
Electric Motor
Removal
1. Turn main power OFF . Disconnect power
supply.
2. Perform the Pressure Relief Procedure, page 25.
3. Remove drive housing/pump assemblies, page 30.
4. Disconnect motor cables as follows:
a. Refer to electrical diagrams. Motor control
board is on right side inside cabinet, see page
36.
b. Unplug motor power harness from connector J4
on board. See FIG. 2, page 37.
c. Unplug 3-pin connector J7 from board.
d. Thread cables through top of cabinet to free
motor.
5. Remove screws holding motor to bracket. Lift motor
off unit.
Installation
1. Place motor on unit. Thread motor cables into
cabinet and into bundles as before. See electrical
diagrams.
2. Fasten motor with screws.
3. Plug 3-pin connector J7 to board.
4. Plug motor power harness to connector J4 on
board.
5. Install drive housing/pump assemblies, page 30.
6. Return to service.
CAUTION
Motor is heavy. Two people may be required to lift.
