Parts
56 312066ZAF
Parts that Vary by Model
Use the following tables on this and the next two pages to find parts that vary by model. Find the reference number
and of part in left column and Reactor model in top row. Intersection is correct part number.
See page 55 for parts common to all models.
Ref. Description
Reactor Models
Qty.
259024
E-XP1
259025
E-20
259026
E-30
259028
E-XP2
259029
E-XP1
259030
E-20
259031
E-30
259032
E-XP2
259033
E-XP1
259034
E-20
259035
E-30
259036
E-XP2
2 HEATER;
pages 62 and
63
247507 247506 247507
247509
(qty: 2)
247507 247506 247507
247509
(qty: 2)
247507 247506 247507
247509
(qty: 2)
1
3 MODULE,
proportioner;
page 59
245956 245956 245957 245959 245956 245956 245957 245959 245956 245956 245957 245959 1
6 CONTROL,
motor; page
67
24G879 24G879 24G881 24G881 24G879 24G879 24G881 24G881 24G879 24G879 24G881 24G881 1
8 TRANSFORM
ER;
247840 247840 247812 247812 247840 247840 247812 247812 247840 247840 247812 247812 1
9 SHIELD 276878 276878 276879 276879 276878 276878 276879 276879 276878 276878 276879 276879 1
14 TUBE, heater,
component A
247920 247920 247920 247915 247920 247920 247920 247915 247920 247920 247920 247915 1
15 TUBE, pump,
component A
247912 247912 247919 247914 247912 247912 247919 247914 247912 247912 247919 247914 1
16 TUBE, heater,
component B
247918 247918 247918 247917 247918 247918 247918 247917 247918 247918 247918 247917 1
17 TUBE, pump,
component B
247913 247913 247921 247916 247913 247913 247921 247916 247913 247913 247921 247916 1
21 CONNECTOR
, tube
121310 121310 121311 121311 121310 121310 121311 121311 121310 121310 121311 121311 2
28 MODULE,
breaker; page
69
CCF FBBEEAADD1
36 SWITCH,
added pole;
380V
123968 123968 123968 123968 1
39 FILTER; 230V
117667 117667 117667 117667 117667 117667 1
