8. Built-in Clock Set-up
Read Chapter 7 Before Use of These Pages
8.3 Time
Select menu item and set the time in the 24 hour
system using the [UNIT] and [PRINT] keys, then
press the [O/T] key.
Example: 1:23 in the afternoon, is set as “13:23”.
8.4 Setting Display During Stand-by
Determine what is to be displayed during stand-by.
To display the time during stand-by, select menu item .
To display the date during stand-by, select menu item .
To display neither during stand-by, select menu item .
64
(Example)
Note
The moment the [O/T] key is pressed seconds are set to 00.
Notes
• Seconds display function:
Press the [UNIT] key to switch on/off of the display of seconds.
