59
13. Enhancing Productivity
Read Chapter 7 Before Use of These Pages
13.3 Auto Print
Auto Print function allows output of the data automatically without pressing the [PRINT] key for each
sample. The “Auto-Print symbol is illuminated when the Auto Print function is activated.
Six types of Auto Print are selectable.
Print on loading: Select menu item .
Load the sample when the value displayed is within the Zero Range. When stability is
detected and the positive displayed value is more than 5 times the Zero Range, data is
automatically output.
The next data output is not performed unless the display has returned to a value within the
Zero Range by unloading the sample or pressing the [O/T] key.
Print on loading and unloading: Select menu item .
Load or unload the sample when the displayed value is within the Zero Range. When stability
is detected and the displayed positive or negative value is more than 5 times the Zero
Range, data is automatically output.
The next data output is not performed unless the display has returned to a value within the
Zero Range by unloading the sample or pressing the [O/T] key.
Print on loading and on zero: Select menu item .
Load the sample when the value displayed is within the Zero Range. When stability is
detected and the positive displayed value is more than 5 times the Zero Range, data is
automatically output.
Unload the sample or press the [O/T] key. When the displayed value is within the Zero
Range and stability is detected, data is output again.
Print on loading, unloading, and on zero: Select menu item .
Load the sample when the value displayed is within the Zero Range. When stability is
detected and the displayed positive or negative value is more than 5 times the Zero Range,
data is automatically output.
Unload the sample or press the [O/T] key. When the displayed value is within the Zero
Range and stability is detected, data is output again.
Print continuously: Select menu item .
Not applicable to a verified balance as a legal measuring instrument in the EU
By pressing the [PRINT] key while the Auto-Print symbol and Stand-by symbol are lit, the
Stand-by symbol goes out, the Communication symbol lights and the displayed data is con-
tinuously output.
Continuous output stops temporarily when the [PRINT] key is pressed.
