11. Environment
Read Chapter 7 Before Use of These Pages
Standard mode: Select menu item .
This mode is suitable for weighing in a normal environment. Averaging is
fixed and does not change dynamically as in the Auto mode.
Anti-vibration mode: Select menu item .
Use this mode when the balance is used in a location where there are large
vibrations and the display fluctuates in the Auto mode.
Response is deteriorated at small mass amount changes.
Anti-wind mode: Select menu item .
Use this mode when the balance is used in a location where it is exposed to
airflow that causes the display to fluctuate in the Auto mode.
Response deteriorates further than the Anti-vibration mode, but weighing is
comparatively stabilized.
11.3 Stability Detection and Settings
Stability detection is an auxiliary function used for the following purposes.
(1) When stability is detected during measurement, Stability mark is illuminated as an auxiliary indi-
cation of measurement stability.
(2) Operations such as data output and auto zeroing of the below listed functions are triggered by
stability detection. Some data output functions operated with communication commands
(15.2.3) are also linked to stability detection.
(Functions that employ stability detection)
Auto Print (See 13.3), Auto Zero (See 13.4), Taring/Printing at Stability (See 13.6), Peak Hold
(See 14.3), Auto-Memory and Zeroing (See 14.5), Animal Weighing (See 14.6), Formulation
Mode (See 14.7).
Note
While “Pouring” is selected as the Stability and Response setting, taring
the container or zeroing the display cannot be made by pressing the right-
most part of [O/T] key. Press the center or the left part of [O/T] key for tar-
ing or zeroing.
Note
If weighing cannot be performed efficiently even with the Anti-wind mode,
change the installation site of the balance or use the optional windbreak
(large).
24
25
26
