10. Calibration

Read Chapter 7 Before Use of These Pages

10.3 Calibration Setting

10.3.1 Selecting the Calibration Type

Set the calibration type that will be used in Calibration Execution.

To set up “Span calibration using the built-in weight”,(UW only) Select menu item .

To set up “Calibration check using the built-in weight”,(UW only) Select menu item .

To set up “Span calibration using external weights”, Select menu item .*

To set up “Calibration check using external weights”, Select menu item .*

*Not applicable to a verified balance as a legal measuring instrument in the EU

10.3.2 PSC Fully-automatic Calibration (UW series only)

With the PSC function, span calibration is performed automatically using the built-in calibration weight

when the balance detects a temperature change that would affect weighing accuracy.

1 To turn ON the PSC function, Select menu item

2 To turn OFF the PSC function, Select menu

item .

Notes

• Blinking calibration symbol indicates an automatic calibration is about to

start.

• If PSC starts while the balance is in use, press the [POWER] key to abort

that cycle.

Note

Using a verified balance as a legal measuring instrument in the EU:

When PSC, fully-automatic span calibration, is not activated, operator must

carry out span calibration with the built-in weight (refer to 10.2.1) upon

blinking of the Weight Symbol.
