11. Environment

Read Chapter 7 Before Use of These Pages

11. Environment

11.1 Overview

Settings on the balance can be changed to compensate for the installation environment such as the

degree of vibration or air movement or for the purpose of weighing a solid, liquid or powder.

11.2 Stability and Response (Averaging)

It is possible to match the stability of the display and the degree of response with the requirements of

specific applications or the installation environment. One of the five modes can be selected. Note that

adjustments for stability and response conflict with each other, although the UW/UX series is designed

to meet both.

Auto mode: Select menu item .

The balance automatically performs optimum averaging dynamically while

observing the load data. This is the recommended setting and should be used

unless special circumstances exist.

Pouring mode: Select menu item .

(Filling, dosing) This mode is particularly suitable for dosing or filling purposes.

Note that this mode is very sensitive to wind and vibration.

(Environmental setting in Pouring mode)

Pouring mode allows further adjustments to the surrounding environmental

conditions. Choose the optimal setting for your installation site observing the

response and stability.

Every time the circle in the right part of the [O/T] key is pressed during weigh-

ing in Pouring mode, the environmental setting will be changed and cycles in

the following order. Upon changing the setting, the new setting is briefly dis-

played as shown in “ ”.

normal environment ( “norm E” ) → unstable environment, ( “UnStb E” )

→very stable environment, ( “StAbL E” ) → normal environment, ( “norm E” ).

During use, the current environmental setting of Pouring mode can be con-

firmed by observing the position of the

W symbol in the display.

(Display)

When “UnStb E” is selected

When “norm E” is selected

When “StAbL E” is selected
