Shimadzu UW-2200H [120/129] A 3 optional accessories list
![Shimadzu UW-2200H [120/129] A 3 optional accessories list](/views2/1910815/page120/bg78.png)
Appendices
104
A-3. Optional Accessories List
Item Part number Description
EP-80 Electronic Printer 321-62675-01
(w/o AC adapter)
Impact dot print, can be used with WindowsDirect
RS-232C Cable 25P-9P (1.5m) 321-60117-01 For PC/AT, DOS/V serial port
IFB-102A RS-232C Interface 321-41167-10 Necessary for multi-connection
IFB-102A-UNC RS-232C Interface 321-41167-20 Inch-size screws type, Necessary for multi-con-
nection
AKB-301 Application Keyboard 321-53382-01
Remote Display RDB-201 321-53600-01 With operation keys
Remote Display RDB-202 321-53600-02 Without operation keys
Windbreak Set 321-62797 For small pan model only (Standard for models
with minimum display of 0.001g)
WBC-102 Glass Windbreak 321-62795 For small pan model only (with three sliding doors)
WBC-502 Large Size Windbreak 321-53537 For all models (opens upward with hinges)
FSB-102PK Foot Switch 321-60110-11 The same effect as [PRINT] key
FSB-102TK Foot Switch 321-60110-12 The same effect as [O/T] key
Animal Bucket Set 321-62150 For animal weighing, for large pan model only
Specific Gravity Measurement Kit SMK-101 321-60576-01 For large pan model only
Specific Gravity Measurement Kit SMK-102 321-60576-02 For small pan model only (except for UW/UX220H)
In-use protective cover
(for large-pan model)
321-53529-01 Covering whole main body
In-use protective cover
(for small-pan model)
321-53529-02 Covering whole main body
Note
Part number and specification are subject to change without notice.
It is not guaranteed that RS-232C cable will conform to all computers.
