48
10. Calibration
Read Chapter 7 Before Use of These Pages
10.4 For GLP/GMP/ISO Conformance
These settings should be made by the administrator.
10.4.1 Calibration Report Setting
Turns the calibration report function ON/OFF. Use this to generate and output a calibration report as for
GLP, GMP, or ISO9000. An electronic printer (optional accessory) is required to print the report.
To create calibration report, Select menu item .
To turn off calibration report function, Select menu item ..
10.4.2 Balance ID Setting
Individual balances can be identified by the serial number on the main body of the balance. The user
can add a four-digit ID number to the calibration report.
Select menu item . Set a 4-digit number from “0000” to “9999”.
Note
Date output, ID number etc. of electronic printer EP-50 or EP-90 should be
turned off when calibration report is produced.
