Do not set the gear selection switch during drilling. With

the gear selection switch, two dierent rotation speed

ranges can be set.

Gear 1:

Low rotation speed range, intended for working with

large drilling diameters.

Gear 2:

High rotation speed range, intended for working with

small drilling diameters.

Setting the rotation speed

By pressing the Rotation speed setting-ring, you can set

the rotation speed during idle operation.

The optimal rotation speed is dependent upon the work

piece, the operation mode, and the inserted drill.

- Light pressure on the Rotation speed setting-ring: low

rotation speed (intended for: small/short screws, soft

working materials);

- Greater pressure on the Rotation speed setting-ring:

higher rotation speed (designated for: large/long screws,

hard working materials).

Selecting the rotation direction

• Do not set the switch left/right rotation during drilling.

• The rotation direction is always according to the switch

position.

• Switch position R: right-rotation/forward/clockwise. To

drill and to screw in screws, push the switch right/left ro-

tation to the right until the stopper.

• Switch position L: left-rotation/backward/coun-

ter-clockwise. To loosen or pull out screws and nuts, push

the switch right/left rotation to the left until the stopper.

Changeover switch (Drilling/ Impact Drilling)

Set the changeover switch only when the impact drill is

at a standstill.

• Drilling operation mode: Set the changeover switch on

the DRILL position work on wood, metal, or plastic mate-

rials;

• Impact drilling operation mode: Set the changeover

switch on the Hammer position to work on concrete,

stone, or brick.

Attachable handle

Never use the impact drill without the attachable handle.

The attachable handle provides additional support and al-

lows you to work exhaustion-free. The attachable handle

is intended for both right-and left-handed persons.

• Loosen the rotating button (a2) of the attachable han-

dle by turning it counter-clockwise.

• Guide the drill chuck of the impact drill through the at-

tachable handle.

• Then turn the attachable handle to the position which is

best for you.

• Turn the rotating button (a2) clockwise until the attach-

able handle sits tightly and can no longer be moved.

Depth gauge

With the depth gauge, you can drill several holes with the

same drilling depth.

• Loosen the rotating button (a2) of the attachable han-

dle.

• Guide the depth gauge through the opening on the at-

tachable handle.

• To set the desired drilling depth.

• Pull the depth gauge out far enough so that the dis-

tance between the point of the drill and the point of the

depth gauge is the desired drilling depth.

• Turn the rotating button (a2) clockwise until the attach-

able handle sits tightly and can no longer be moved.

MAINTENANCE AND CLEANING

Make sure that the machine is not live when carry-

ing out maintenance work on the motor.

• Regularly clean the machine housing with a soft cloth,

preferably after each use. Keep the ventilation slots free

from dust and dirt.If the dirt does not come o use a soft

cloth moistened with soapy water. Never use solvents

such as petrol, alcohol, ammonia water, etc. These sol-

vents may damage the plastic parts.

• The machine requires no additional lubrication.

• Should a fault occur, e.g. after wear of a part, please con-

tact your local BORT GLOBAL LIMITED dealer.

DISPOSAL

Discarded electric appliances are recyclable

and should not be discarded in the domestic

waste! Please actively support us in conserving

resources and protecting the environment by

returning this appliance to the collection cen-

tres (if available).

Made in China.
