Pioneer FH-X360UB [6/32] Audio adjustments

Black plate (6,1)

S.RTRV (sound retriever)

Automatically enhances compressed audio and

restores rich sound.

1 Press M.C. to select the desired setting.

1—2—OFF (off)

1 is effective for low compression rates, and 2

is effective for high compression rates.

Audio adjustments

1 Press M.C. to display the main menu.

2 Turn M.C. to change the menu option

and press to select AUDIO.

3 Turn M.C. to select the audio function.

Once selected, the following audio functions

can be adjusted.

! FADER is not available when SUB.W/SUB.W

is selected in SP-P/O MODE. For details, refer

to SP-P/O MODE (rear output and preout set-

ting) on page 7.

! SUB.W and SUB.W CTRL are not available

when REAR/REAR is selected in

SP-P/O MODE. For details, refer to

SP-P/O MODE (rear output and preout set-

ting) on page 7.

! SUB.W CTRL is not available when SUB.W is

selected in OFF. For details, refer to SUB.W

(subwoofer on/off setting) on page 6.

! SLA is not available when FM is selected as

the source.

FADER (fader adjustment)

1 Press M.C. to display the setting mode.

2 Turn M.C. to adjust the front/rear speaker bal-

ance.

BALANCE (balance adjustment)

1 Press M.C. to display the setting mode.

2 Turn M.C. to adjust the left/right speaker bal-

ance.

EQ SETTING (equalizer recall)

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the equalizer.

POWERFUL—NATURAL—VOCAL—CUS-

TOM1—CUSTOM2—FLAT—SUPER BASS

The equalizer band and equalizer level can be

customized when CUSTOM1 or CUSTOM2 is

selected.

If selecting CUSTOM1 or CUSTOM2, complete

the procedures outlined below. If selecting

other options, press M.C. to return to the pre-

vious display.

! CUSTOM1 can be set separately for each

source.

! CUSTOM2 is a shared setting used in com-

mon for all sources.

3 Press M.C. to display the setting mode.

4 Press M.C. to cycle between the following:

Equalizer band—Equalizer level

5 Turn M.C. to select the desired setting.

Equalizer band: 80HZ—250HZ—800HZ—

2.5KHZ—8KHZ

Equalizer level: +6 to –6

! You can also switch the equalizer by pressing

repeatedly.

LOUDNESS (loudness)

Loudness compensates for deficiencies in the low-

frequency and high-frequency ranges at low vol-

ume.

1 Press M.C. to select the desired setting.

OFF (off)—LOW (low)—MID (mid)—HI (high)

SUB.W (subwoofer on/off setting)

This unit is equipped with a subwoofer output

which can be turned on or off.

1 Press M.C. to select the desired setting.

NOR (normal phase)—REV (reverse phase)—

OFF (subwoofer off)

SUB.W CTRL (subwoofer adjustment)

Only frequencies lower than those in the selected

range are outputted from the subwoofer.

1 Press M.C. to display the setting mode.

2 Press M.C. to cycle between the following:

Cut-off frequency—Output level—Slope level

Rates that can be adjusted will flash.

3 Turn M.C. to select the desired setting.

Cut-off frequency: 50HZ—63HZ—80HZ—

100HZ—125HZ—160HZ—200HZ

Output level: – 24 to +6

Slope level: –12— –24

BASS BOOST (bass boost)

1 Press M.C. to display the setting mode.

2 Turn M.C. to select a desired level.

0 to +6 is displayed as the level is increased or

decreased.

HPF SETTING (high pass filter adjustment)

Use this function when wanting to listen only to

high-frequency sounds. Only frequencies higher

than the high-pass filter (HPF) cutoff are output

from the speakers.

1 Press M.C. to display the setting mode.

2 Press M.C. to cycle between the following:

Cut-off frequency—Slope level

3 Turn M.C. to select the desired setting.

Cut-off frequency: OFF—50HZ—63HZ—80HZ

—100HZ—125HZ—160HZ—200HZ

Slope level: –12— –24

SLA (source level adjustment)

This function prevents the volume from changing

too dramatically when the source switches.

! Settings are based on the FM volume level,

which remains unchanged.

! The MW/LW volume level can also be adjusted

with this function.

1 Press M.C. to display the setting mode.

2 Turn M.C. to adjust the source volume.

Adjustment range: +4 to –4

System menu

Important

PW SAVE (power saving) is canceled if the ve-

hicle battery is disconnected and will need to be

turned back on once the batter y is reconnected.

When PW SAVE (power saving) is off, depend-

ing on connection methods, the unit may con-

tinue to draw power from the battery if your

vehicle’s ignition doesn’t have an ACC (acces-

sory) position.

1 Press M.C. to display the main menu.

2 Turn M.C. to change the menu option

and press to select SYSTEM.

3 Turn M.C. to select the system menu

function.

Once selected, the following system menu func-

tions can be adjusted.

LANGUAGE (multi-language)

1 Press M.C. to select the desired setting.

РУС (Russian)—TUR (Turkish)—ENG (Eng-

lish)

CLOCK SET (setting the clock)

Using this unit

Section

Using this unit

<QRB3357-A>6
