Samsung LW-46G15 W [62/72] Connecting to the active sub woofer speaker

English - 62

Connecting to the Active Sub Woofer Speaker

The SUB WOOFER OUT connector is used for active sub woofer speaker with a woofer in.

TV Rear View

Active Sub Woofer

Speaker

BN68-00746A(GAIA2_Euro_ENG) 2004/08/23 03:56 PM Page 62
