LG GW-P207FTQA [27/39] Operation
![LG GW-P207FTQA [27/39] Operation](/views2/1093494/page27/bg1b.png)
27
Operation
The humidity can be controlled by adjusting the humidity control switch to the
left/right when storing vegetables or fruits.
▪ The bottom drawer in the refrigerator can be converted into a vegetable or
meat compartment
The meat compartment maintains the temperature at a lower point than the
refrigerator compartment so that meat or fish can be stored fresh longer.
Humidity control in the vegetable compartment
(Applicable to some models only)
Convert into a vegetable or meat compartment
(Applicable to some models only)
NOTE
• Vegetables or fruit will be frozen if the conversion switch is set to meat
compartment. Be sure to check its position before storing foods.
High humidity
Low humidity
Vegetable
compartment
Meat compartment
Conversion
switch
Be sure
to check the
conversion switch
before storing
foods
Operation
You can store taller items such as a gallon container or bottles by simply pushing in
front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf.
ENGLISH
ENGLISH
