![LG GW-P207FTQA [38/39] Care and maintenance](/views2/1093494/page38/bg26.png)
3838
Care and maintenance
Care and maintenance
Occurrence Possible cause Solution
Odours in refrigerator
Interior needs to be cleaned. Clean interior with sponge,warm
water and baking soda.
Food with strong odour is in the refrigerator. Cover food completely.
Some containers and wrapping materials
produce odours.
Use a dierent container or brand of
wrapping materials.
Opening/Closing of
doors/Drawers
Door(s) will not close. Food package is keeping door open. Move packages that keep door from
closing.
Door was closed too hard, causing other
door to open slightly
Close both doors gently.
Refrigerator is not level. It rocks on the oor
when it is moved slightly.
Adjust the height adjusting screw.
Floor is uneven or weak. Refrigerator rocks
on the oor when it is moved slightly.
Be sure oor is level and can
adequately support refrigerator.
Contact carpenter to correct sagging
or sloping oor. It is normal for the
refrigerator to have a slight lean
backwards.
Refrigerator is touching wall or cabinets. Move refrigerator.
Drawers are dicult
to move.
Food is touching shelf on top of the drawer. Keep less food in drawer.
Track that drawer slides on is dirty. Clean drawer and track.
Dispenser
Dispenser will not
dispense ice
Ice storage bin is empty. When the rst supply of ice is
dropped into the bin, the dispenser
should operate.
Freezer temperature is set too warm. Turn the freezer control to a higher
setting so that ice cubes will be
made. When the rst supply of ice is
made,the dispenser should operate.
Household water line valve is not open. Open household water line valve
and allow sucient time for ice to be
made. When ice is made, dispenser
should operate.
Refrigerator or freezer door is not closed. Be sure both doors are closed.
Occurrence Possible cause Solution
Dispenser will not
dispense ice.
Ice has melted and frozen around auger due
to infrequent use, temperature fluctuations
and/or power outrages.
Remove ice storage bin, and thaw and
the contents. Clean bin, wipe dry and
replace in proper position. When new
ice is made, dispenser should operate.
Ice dispenser is
jammed.
Ice cubes are jammed between the icemaker
arm and back of the bin.
Remove the ice cubes that are jamming
the dispenser.
Ice cubes are frozen together. Only the ice cubes made by the
ice maker should be used with the
dispenser.
Ice cubes that have been purchased or
made in some other way have been used in
the dispenser.
Use a dierent container or brand of
wrapping materials.
Dispenser will not
dispense water.
Household water line valve is not open. See
problem “Ice maker is not making any ice.”
Open household water line valve.
Refrigerator or freezer door is not closed. Be sure both doors are closed.
Water has an odd taste
and/or odour.
Water has been in the tank for too long. Dispense and discard 7 glasses of
water to freshen the supply. Dispense
and discard an additional 7 glasses to
completely rinse out tank.
Unit not properly connected to cold water
line.
Connect unit to cold water line which
supplies water to kitchen tap.
Sound of ice dropping This sound is normally made when automatically made ice is dropped into ice storage
bin. Volume may vary according to refrigerator’s location.
Sound of water supply This sound is normally made when ice maker is supplied with water after dropping the
automatically made ice.
Other Please thoroughly read ‘Automatic ice maker and dispenser’ in this manual.
Display shows the
word ____
The refrigerator control has been put into the store Demo(Demonstration) Mode.
The Demonstration Mode disables the cooling system,only lamps and display work
normally. To disable Demo Mode open one door, then press EXPRESS FRZ.
and REF. TEMP buttons at the same time for 5 seconds. You will see the previous value
setting you had on display when Demo Mode is deactivated.
