Zelmer 986.80 (83) (86) (87) (88) [73/75] Quern grinder fig 10

Insert the assembled squeezer onto the motor,

●

proceeding in the same way as in the description of the

mincing chamber.

Insert the bowl

●

(7) and the pusher (8) – from the mincing

unit onto the feeding tube.

Put some appropriate vessels for juice and pulp under

●

the juice channel outlet (5) and adjusting screw (6).

Plug in the appliance.

●

Turn on the appliance by pressing the

●

„I” button and

next insert the fruits pushing them with the pusher.

In order for the juice squeezing process to run properly

do not screw the adjustment screw too deeply in the initial

operation phase. After assessing the amount of juice in

the processed fruits, adjust the screw in order to obtain an

adequate effectiveness and to avoid clogging the appliance.

Observe the pulp dryness during squeezing. If they

●

are too dry, unscrew the adjusting screw (6), to avoid

clogging the appliance.

The screw adjustment depends on the type of processed

fruits, in case of juicy and ripe fruits adjust the screw

deeper, and for fruits that are not as juicy, the level of screw

adjustment should be lower.

If the screw adjustment does not provide an adequate

squeezing effectiveness, you can process the processed

fruits once again.

The clogging of the chamber outlet (in the adjustment screw

(3)) with juicy processed fruits can cause the juice to contact

the motor.

Unplug the appliance if the chamber outlet becomes

clogged. Pay special attention during the juice squeezing

process, make sure the screen openings are not clogged.

Dismantle the juicer from the motor (as in the case of the

mincing chamber), dismantle the squeezer, clean (wash)

the squeezer elements. Use the included brush to clean the

appliance, especially the screen.

Quern grinder (Fig. 10)

I. Nut

II. Quern regulator

III. Body with handle

IV. Internal quern

V. External quern

VI. Worm

VII. Grinder chamber

VIII. Pan

IX. The groove of the body has to hit the protrusion of the

grind chamber

Device description

Presented device can be used to grinding such products as:

corns, oily seeds and the dry comestibles

The quern grinder enables grinding of such products as:

wheat, oat, rice, granular coffee, all-spice, charlock, walnuts,

hazel-nuts dried mushrooms, almonds, soya. linseed,

buckwheat groats, peeled sunower seeds etc.

IMPORTANT: Don`t grind the oily products by the

minimal granulation set up. Grinding device can be

glued or blocked.

IMPORTANT: Device is not dedicated for grinding the

very hard products as f. e. dried pea, maize, popcorn.

The installation of the grinder on the device

When the grinder chamber is turned right through the angle

of 45, put the assembled grinder on the drive by putting the

protrusions of grinder chamber (7) on the recesses of the

drive, and then, turn left to the position in which you will hear

“clicking” of the blocking. It means that the grinder has been

assembled correctly.

Usage and regulation of the grinder

Before the rst use, wash (see “CLEANING”) and dry

a disassembled grinder, and then grind around 50 grams of

product (f. e. corns) - set-up the grinding option of the device

with the medium comminute. The grinded product is not t to

use cause it` s polluted and its necessary throw it away.

IMPORTANT: Maximal time of uninterrupted work is

around 15 minutes.

This condition is connected with maximal work time of

machine, for which it should be done the 45 minutes of

pause after 15 minutes of operation.

IMPORTANT: The devices cannot operate without

loading. Each time before staring the device, ll it up

with product.

Put the corns into the pan (8), set up the handle of the body

(3) on the thicker grinding, set up the machine engine. The

grinded product will start pouring out through the hole.

Regulate the quern regulator (2), depending of the demanded

grinding level or using seeds, with the handle of the body for

obtain the product with the adequate granulation level.

By turning it clockwise you will get the ne grind product. By

turning it counter-clockwise – the thick grind product.

The nest (minimal) grinding level is achieved by setting it

up with the handle on the line 1, and the hugest (maximal)

by setting it up with the handle on the STOP line. See the

graphic on the body (3) and quern regulator (2).

Too strong twisting or turning of the handle out of STOP

line during the work time can cause the device failure.

CAUTION: It` s recommended to set the quern

regulator during the grinder work time between the

line 1 and STOP line.

IMPORTANT: It`s FORBIDDEN to use the REVERSE

function in the machine when the grinder is installed.

CAUTION: Remember about the accurate washing the

grinder before grinding of the different products. It will

permit to avoid the mutual penetration of odors.

CAUTION: For the soft corns as oat or linseed it`s

necessary to select the coast-grained set up.
