20
•Iftheidenticationlabelandthewarninglabelsdeteriorateduringuse,contactyourdealeroranauthorised
servicecentresotheycanbereplaced.
3.2standardaCCessorIes
Make sure that in the product package that was bought there are the following elements:
high-pressure water cleaner;
high-pressure delivery pipe with fast coupling (only PW 160 - IP 1600);
hose reel complete with high-pressure delivery pipe (only PW 160C - PW 170C - IP 1700S);
water gun;
lance hose;
rotojet (only PW 160C - PW 170C - IP 1700S);
foaming lance (only PW 160 - PW 160C - IP 1600);
operator's instruction book;
accessory bag containing:
- lance hose nozzle disassembling wrench,
- nozzle cleaning pin,
- water suction hose-holding connector,
- water suction lter;
bag containing (only PW 160C - PW 170C - IP 1700S):
- knob and lever for hose reel (13),
- water cleaner/hose reel connecting pipe (25),
- accessory support (26).
In case of problems, apply to the dealer or to an authorised service centre.
3.3optIonalaCCessorIes
The standard accessories for the high pressure cleaner can be integrated with the following vast range of accessories:
Sandblasting lance: designed for smoothing down surfaces, eliminating rust, paint, deposits etc.
Pipe-draining probe: designed for unblocking pipes and ducts.
Underbody lance: designed to reach the most difcult areas of access.
Rotating water jet brush: designed for cleaning delicate surfaces.
Rotojet: designed to eliminate the toughest dirt.
Foaming lance: designed for the most efcient distribution of detergent.
WArnInG
•Theoperationofthewatercleanermaybeimpairedifunsuitableaccessoriesareusedandtheymayevenmake
itdangerous.OnlyuseoriginalaccessoriesendorsedbytheManufacturer.
Refertothedocumentsprovidedwiththeoptionalaccessoriesforinformationregardingtheirgeneraluse,safety
warnings,installationandmaintenance.
4 InstallatIon
See Fig. A at the front of these operating and maintenance instructions.
4.1assemblInGtheaCCessorIes
a) Insert the lance hose (11) on the water gun (8) and tighten.
b) Mount the accessory support (26) on the handlebar (30); mount the knob and the lever (13) on the hose reel (6)
(only PW 160C - PW 170C - IP 1700S).
c) Mount the hose (25) between the hose reel and the water cleaner, by tightening the two fast coupling connectors;
unroll the hose quantity (7) that is necessary by rotating the hose reel by means of the knob (13) (only PW 160C -
PW 170C - IP 1700S).
d) Unroll the high-pressure hose (7), connect the fast coupling connector to the water outlet connector (5), screw and
tighten (only PW 160 - IP 1600).
e) Screw the end of the high-pressure pipe (7) (side without fast coupling for PW 160 - IP 1600) on the water gun
thread (8) and tighten with two 17-mm box wrenches (not supplied).
f) Insert the water suction lter (15) into the water suction connector (14) and tighten it on the water inlet connector
of the water cleaner.
