USING THE RADIO CONTROL

WARNINGS!:

Place the hood away from sources of electromagnetic waves (e.g.

microwave ovens), which could interfere with the radio control

and with the hood electronics.

The maximum operating distance is 5 metres, that may vary according to

the presence of electromagnetic interferences.

Radio control operated at 433.92MHz.

The radio control consists of two parts:

- the receiver built into the hood;

- the transmitter shown here in the gure.

DESCRIPTION OF TRANSMITTING COMMANDS

Motor switch-on and speed increase

from 1 to 4. Speed 4 is only active for a

few minutes.

DOWN

Speed decrease and motor switch-oﬀ.

Light ON-OFF

Short impulse:

turn light on and oﬀ

Long impulse:

change light tone from 2700K to 5600K

TIMER ON: The motor automatically

switches oﬀ after 15 min.

The function is automatically disabled if

the motor is switched oﬀ ( key)

Command transmission active

The radio control is optional for the GRUPPO INCASSO and Green Tech.

Follow the entire procedure described below if purchased.

Skip the activation procedure for IL GRUPPO INCASSO MURANO.

ACTIVATION PROCEDURE (for GRUPPO INCASSO and Green Tech)

Before using the radio control, follow the procedure below on the hood push-

button panel:

• Press LIGHT (

) and TIMER ( ) simultaneously until all LEDs start ﬂashing.

• Release the two keys and press LIGHT ( ) again until all LEDs are lit up.

• Release LIGHT (

): now the receiver is active.

This procedure is also used to deactivate the receiver.

RADIO CONTROL CODE CHANGE

With only one radio control, go directly to point 2.

With several radio controls in the same room, a new code can be created by

following the procedure below.

Disconnect the power to the hood before starting the procedure.

1  CREATE A NEW CODE

The procedure is to be carried out on the radio control.

• Press LIGHT and TIMER simultaneously until the display starts ﬂashing.

• Press DOWN

on the radio control: saving is conﬁrmed by three brief ﬂash-

es of the display. The new code cancels and replaces the previous default

code.

Reconnect the hood to the electrical power supply, making sure

that the lights and motor are o.

2A  ASSOCIATING THE RADIO CONTROL WITH THE HOOD

USING THE ELECTRONIC PUSHBUTTON PANEL

press TIMER ( ) on the hood pushbutton panel for 2 seconds:

the red LED lights up.

press any key on the radio control within 10 seconds.

2B  ASSOCIATING THE RADIO CONTROL WITH THE HOOD

USING THE TOUCH PUSHBUTTON PANEL

press TIMER ( ) on the hood pushbutton panel for 2 seconds:

the red LED lights up.

press any key on the radio control within 10 seconds.

RESTORING DEFAULT CODE

the procedure is to be carried out if the hood is disposed of, sold or transferred.

Disconnect the power to the hood before starting the procedure.

• Press UP

and DOWN simultaneously on the radio control for more

than 5 seconds: reset is conﬁrmed by three brief ﬂashes of the display.

• Reconnect the hood to the electrical power supply.

• Proceed with associating the hood and the radio control, as described in

point 2.

MAINTENANCE

Before cleaning or carrying out maintenance operations, discon-

nect the equipment by removing the plug or switching o the

main switch.

Do not use detergents containing abrasive, acidic or corrosive substances

or abrasive cloths.

Regular maintenance guarantees proper operation and performance over time.

Special attention is to be paid to the metal anti-grease lters : frequent clean-

ing of the ﬁlters and their supports ensures that no ﬂammable grease is accu-

mulated.

CLEANING OF EXTERNAL SURFACES

You are advised to clean the external surfaces of the hood at least once every

15 days to prevent oily substances and grease from sticking to them. To clean

the brushed stainless steel hood, the Manufacturer recommends using "Magic

Steel" wipes.

Alternatively and for all the other types of surfaces, it can be cleaned using a

damp cloth, slightly moistened with mild, liquid detergent or denatured alcohol.

Complete cleaning by rinsing well and drying with soft cloths.

Do not use too much moisture or water around the push button

control panel and lighting devices in order to prevent humidity

from reaching electronic parts.

The glass panels can only be cleaned with speciﬁc, non-corrosive or non-abra-

sive detergents using a soft cloth.

The Manufacturer declines all responsibility for failure to comply with these in-

structions.

CLEANING OF INTERNAL SURFACES

Do not clean electrical parts, or parts related to the motor inside

the hood, with liquids or solvents.

For the internal metal parts, see the previous paragraph.

METAL ANTI-GREASE FILTERS

It is advised to frequently wash the metal ﬁlters (at least once a month) leaving

them to soak in boiling water and cleaning solution for 1 hour, taking care not

to bend them.

Do not use corrosive, acid or alkaline detergents.

Rinse them well and wait for them to be completely dry before reassembling

them.

Washing in a dishwasher is permitted, however, it may cause the ﬁlter material to

darken: to reduce the possibility of this problem from happening, use low-tem-

perature washes (55°C max.).

To extract and insert the metal anti-grease ﬁlters see the assembly instructions.

ACTIVE CARBON FILTERS

These ﬁlters retain the odours in the air that passes through them. The puriﬁed

air is recirculated into the environment.

The active carbon ﬁlters must be replaced on average every 3-4 months under

normal conditions of use.

See assembly instructions to replace the active carbon ﬁlters.
