ENGLISH

The yellow/green earth cable must not be cut o by the switch.

The Manufacturer declines all responsibility for failure to comply with the safety

regulations.

FUMES DISCHARGE

EXTERNAL EXHAUST HOOD SUCTION

In this version the fumes and vapours are discharged outside

through the exhaust pipe.

To this end, the hood outlet tting must be connected via a

pipe, to an external output.

The outlet pipe must have:

• a diameter not less than that of the hood tting.

• a slight slope downwards (drop) in the horizontal sections to prevent conden-

sation from owing back into the motor.

• the minimum required number of bends.

• the minimum required length to avoid vibrations and reduce the suction per-

formance of the hood.

You are required to insulate the pipes if it passes through cold environments.

In the presence of motors with 800m

/h or higher, a check valve is present to

prevent external air owing back.

Deviation for Germany:

when the kitchen hood is used at the same time as appliances that are powered by

energy other than electricity, the negative pressure in the room must not exceed 4 Pa

(4 x 10-5 bar).

HOOD WITH INTERNAL RECIRCULATION FILTERING

In this model, the air passes through the charcoal lters to be

puried and recycled in the environment.

Ensure that the active carbon lters are assembled into the

hood, if not, install them as indicated in the assembly instruc-

tions.

In this version the check valve must not be assembled: remove it if it is

on the air outlet tting of the motor.

ASSEMBLY INSTRUCTIONS

only intended for personnel qualied

The hood can be installed in various congurations.

The generic assembly steps apply to all installations; for each case,

follow the specic steps provided for the required installation.

OPERATION

WHEN TO TURN ON THE HOOD?

Switch on the hood at least one minute before starting to cook to direct fumes

and vapours towards the suction surface.

After cooking, leave the hood operating until complete extraction of all vapours

and odours. By means of the Timer function, it is possible to set auto switch-o

function which will allow the hood to turn o automatically after 15 minutes of

operation.

WHICH SPEED IS TO BE SELECTED?

1st speed: maintains the circulation of clean air with low electricity consump-

tion.

2nd speed: normal conditions of use.

3rd speed: presence of strong odours and vapours.

4th speed: rapid disposal of odours and vapours.

WHEN SHOULD THE FILTERS BE WASHED OR REPLACED?

The metal lters must be cleaned every 30 hours of operation.

For further details see the “MAINTENANCE” chap.

ELECTRONIC PUSHBUTTON PANEL

Motor ON/OFF

Increase speed from 1 to 4

Speed 4 is only active for a few

minutes, then speed 3 activates.

The speeds are indicated by the

LEDs on the keys:

Speed 1

Speed 2

Speed 3

Speed 4

("+" LED ashing)

Reduce speed from 4 to 1

Light on/o

Short impulse: turn light on and o

Long impulse: change light tone from 2700K to 5600K

TIMER (red LED ashing)

Auto switch-o after 15 min.

The function deactivates (red LED o) if:

- The TIMER key (

) is pressed again.

- The ON/OFF key (

) is pressed.

If the pushbutton panel is completely inactive, before contacting

the Technical assistance service, disconnect power temporarily

to the appliance (about 5“), possibly by acting on the main swi-

tch, to restore normal operation.

If this measure has no eect, contact the Technical assistance service.

USING THE RADIO CONTROL OPTIONAL

WARNINGS!:

Place the hood away from sources of electromagnetic waves (e.g.

microwave ovens), which could interfere with the radio control

and with the hood electronics.

The maximum operating distance is 5 metres, that may vary according to

the presence of electromagnetic interferences.

Radio control operated at 433.92MHz.

The radio control consists of two parts:

- the receiver built into the hood;

- the transmitter shown here in the gure.

DESCRIPTION OF TRANSMITTING

COMMANDS

Motor switch-on and speed increase

from 1 to 4. Speed 4 is only active for a

few minutes.

DOWN

Speed decrease and motor switch-o.

Light ON-OFF

Short impulse:

turn light on and o

Long impulse:

change light tone from 2700K to 5600K

TIMER ON: The motor automatically

switches o after 15 min.

The function is automatically disabled if

the motor is switched o (

key)

Command transmission active

ACTIVATION PROCEDURE

Before using the radio control, follow the procedure below on the hood push-

button panel:

• Press LIGHT (

) and TIMER ( ) simultaneously until all LEDs start ashing.

• Release the two keys and press LIGHT ( ) again until all LEDs are lit up.

• Release LIGHT ( ): now the receiver is active.

This procedure is also used to deactivate the receiver.
