CN9000/CN9600/CN9950 User Manual
164
Specifications
CN9000
Connectors
Console Ports 2 x USB Type-A Female (White)
1 x VGA Female (Blue)
1 x 3.5 mm Audio Jack Female (Green)
1 x 3.5 mm Audio Jack Female (Pink)
KVM Ports 1 x SPHD / VGA Female (Yellow)
1 x 3.5 mm Audio Jack Female (Green)
1 x 3.5 mm Audio Jack Female (Pink)
LAN Ports 2 x RJ-45 Female
Virtual Media 1 x USB Mini-B Female
Power 2 x DC Jack
Serial Port 2 x RJ-45 Female
Control Port 1 x PS/2 Female
Switches
Reset 1 x Semi-recessed pushbutton (Black)
Emulation
Keyboard / Mouse PS/2, USB
LEDs
Power 2 (Green)
Video
Local Console & Remote up to 1920 x 1200 @ 60 Hz
Power Consumption
DC5V:7.46W:39BTU
Environment
Operating Temperature 0 – 50 ºC (CN9000)
0 – 40 ºC (Power Adapter)
Storage Temperature –20 – 60 ºC
Humidity 0 – 80% RH, Non-condensing
