17
Chapter 2
Hardware Setup
Mounting
The KVM over IP Switch can be mounted on most standard 19” (1U) racks or
mounted on a wall. The following illustrations are exemplified using CN9600.
Attaching the Bracket
1. Detach the screws from the underside of the unit as shown:
M3 x 5
1. Important safety information regarding the placement of this
device is provided on page 137. Please review it before
proceeding.
2. Make sure that the power to any device that you connect to the
installation has been turned off. You must unplug the power
cords of any computers that have the Keyboard Power On
function.
3. Any installation that does not follow the instructions in this
guide may be hazardous or cause damage to the device.
4. The power source for this product is intended to be supplied by
a power adapter only, not a DC mains.
5. Please operate the device with caution when under high
environmental temperatures, as the surface of the device may
become overheated under such conditions. For instance, the
surface temperature of the device may reach 70 ºC (158 ºF) or
higher when the environmental temperature reaches close to 50
ºC (122 ºF).
