Appendix
167
CN9950
Connectors
Console Ports 2 x USB Type-A Female (White)
1 x DisplayPort Female (Black)
1 x 3.5 mm Audio Jack Female (Green)
1 x 3.5 mm Audio Jack Female (Pink)
KVM Ports 1 x USB Type-B Female (White)
1 x DisplayPort Female (Black)
1 x 3.5 mm Audio Jack Female (Green)
1 x 3.5 mm Audio Jack Female (Pink)
LAN Ports 2 x RJ-45 Female
Virtual Media 1 x USB Mini-B Female
Power 2 x DC Jack
Serial Port 2 x RJ-45 Female
Control Port 1 x PS/2 Female
Switches
Reset 1 x Semi-recessed pushbutton (Black)
Emulation
Keyboard / Mouse USB
LEDs
Power 2 (Green)
Video
Local Console & Remote 4096 x 2160 @ 30 Hz
Power Consumption
DC5V:9.76W:50BTU
Environment
Operating Temperature 0 – 50 ºC (CN9950)
0 – 40 ºC (Power Adapter)
Storage Temperature –20 – 60 ºC
Humidity 0 – 80% RH, Non-condensing
Physical Properties
