Chapter 5. CLI Commands
91
Command Verification
After entering a command, a verification message appears at the end of the
command line as follows:
Command OK - indicates that the command is correct and successfully
performed by the switch
Command incorrect - indicates that the command has the wrong format
and/or values.
Commands
After connecting to the VM6404HB via Telnet or RS-232, you can operate the
system using the following commands.
Switch Port Command
The Switch Port command allows you to switch ports on the VM6404HB.
The formula for the Switch command is as follows.
Command + Input + Number + Output + Number + Control + [Enter]
1. For example, to switch input port 02 to output port 04, type:
sw i02 o04 [Enter]
2. To switch output port 04 to the next port, type:
sw o04 + [Enter]
3. To turn off video output on port 03, type:
sw o03 off [Enter]
4. To switch audio from input port 06 to stereo audio output, type:
sw i06 console audio [Enter]
The following tables show the possible values for the Switch Port command:
Command Description
sw Switch command
Input Command Description
i Input command
Port number Description
xx 01~04 or 01~08 port
