Aten VM6404HB [15/129] Required devices and accessories

Chapter 1. Introduction

Required Devices and Accessories

Prepare the following devices and accessories before installing the

VM6404HB.

 Up to 4 computers or AV devices equipped with an HDMI Type-A output

connector

Note: To connect a DVI source device, use a DVI-HDMI adapter.

 Display devices or receivers with an HDMI Type-A input connector

 Cables

 1 HDMI cable for each source device

 1 HDMI cable for each display device

 1 Cat 5e cable

 1 RS-232 serial cable

Note:

No cables are included in this package. We strongly recommend that

you purchase high-quality cables of appropriate length since this

will affect the quality of the audio and video display. Contact your

dealer to purchase the correct cable sets.
