Aten VM6404HB [6/129] Package contents

VM6404HB User Manual

Package Contents

Check to make sure that all the components are in working order. If you

encounter any problem, please contact your dealer.

The VM6404HB package consists of:

 1 VM6404HB 4 x 4 True 4K HDMI Matrix Switch with Scaler

 1 power cord

 1 IR remote control

 1 IR receiver

 1 mounting kit

 1 user instructions
