VM6404HB User Manual
xi
About this Manual
This User Manual is provided to help you get the most from your VM6404HB
system. It covers all aspects of installation, configuration and operation. An
overview of the information found in the manual is provided below.
Chapter 1 Introduction, introduces you to the VM6404HB system. Its
purpose, features and benefits are presented, and its front and back panel
components are described.
Chapter 2 Hardware Setup, describes how to set up your VM6404HB
installation.
Chapter 3 Front Panel Configuration, explains the fundamental
concepts involved in operating the VM6404HB at the local site via the front
panel LCD display using pushbuttons.
Chapter 4 Browser Operation, provides a complete description of the
VM6404HB's Browser Graphical User Interface (GUI), and how to use it to
remotely configure and operate the VM6404HB.
Chapter 5 CLI Commands, provides a complete list of the serial control
protocol commands used when utilizing the RS-232 Serial Port so that an extra
source device can be utilized in the installation.
Appendix, which provides specifications and other technical information
regarding the VM6404HB.
Note:
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit or any connected
devices.
The product may be updated, with features and functions added, improved
or removed since the release of this manual. For an up-to-date user
manual, visit http://www.aten.com/global/en
