![SNR UPS-ONRT-25-INTXL33 [10/53] Ups configuration](/views2/1978799/page10/bga.png)
Installation Instruction
6 HR33 Rack Mounted UPS 25KVA User Manual
2.2.2 UPS configuration
The configuration table for UPS is shown in table 2.2:
Table 2.2 UPS configuration table
Item
Components
Quantity
Remark
Dual Input
3
Standard
Dry Contact Card
1
Standard
Cold start
1
Standard
Parallel Card
1
Optional
Circuit Breakers
1
Optional
Battery
1
Optional
2.3 Appearance and Configuration
2.3.1 Appearance
The appearance of the UPS is shown in Figure 2-1:
Figure 2-1 UPS Outlook
Note: Non professionals are forbidden to open the case cover, otherwise there may be an
electric shock hazard
2.3.2 Configuration
Operation display panel:
The UPS front panel unit is shown in Figure 2-1. The operation display panel is located on
the front panel of the UPS, providing the LED indicator, the LCD display and the control
button. See the "operation display panel" for more details".
Rear panel
As shown in Figure 2-2, the UPS rear panel offers the following components:
SNMP
Parallel（Optional）
RS484
RS232
USB（Optional）
Connector
Dry Contact
LBS（Optional）
