HR33 Rack Mounted UPS 25KVA User Manual 11
Installation Instruction
3. Installation Instruction
This chapter introduces UPS installation, include unpacking and inspection, main
Cabinet Installation, cables connection.
3.1 Unpacking and Inspection
1) Unpack the packaging and check the package contents. The shipping package
contains:
● 1 UPS
● 1 user manual
2) Inspect the appearance of the UPS to see if there is any damage during
transportation. Do not turn on the unit and notify the carrier and dealer immediately if
there is any damage or lacking of some parts.
3) If you need tower type installation, you need to find the support block and the middle
seat in advance. You need a support seat and 2 middle seats
3.2 Notes for Installation
1) The UPS must be installed in a location with good ventilation, far away from
water, inflammable gas and corrosive agents.
2) Ensure the air vents on the front and rear of the UPS are not blocked. Allow at
least 0.5m of space on each side.
3) Condensation to water drops may occur if the UPS is unpacked in a very low
temperature environment. In this case it is necessary to wait until the UPS is
fully dried inside out before proceeding installation and use. Otherwise there
are hazards of electric shock.
NOTICE：UPS operation in sustained temperature outside the range of
15-25C (59-77F) reduces battery life.
3.3 Main Cabinet Installation
Two installation modes are available: Tower installation and Rack installation,
depending on available space and user considerations. You can select an appropriate
installation mode according to the actual conditions.
3.3.1 Tower Installation
Various installation configurations are available: single UPS, single UPS with single
or multiple battery cabinets. Their installation methods are all the same.
Please prepare support bases and spacers before installation
1) Take out the support bases and spacers and then assemble the spacer and the
support bases, shown as Fig.3-1.
