HR33 Rack Mounted UPS 25KVA User Manual 1
Safety Precautions
1. Safety Precautions
This manual contains information concerning the installation and operation of Tower
UPS. Please carefully read this manual prior to installation.
The UPS cannot be put into operation until it is commissioned by engineers approved
by the manufacturer (or its agent). Not doing so could result in personnel safety risk,
equipment malfunction and invalidation of warranty.
Safety Message Definition
Danger: Serious human injury or even death may be caused, if this requirement is
ignored.
Warning: Human injury or equipment damage may be caused, if this requirement is
ignored.
Attention: Equipment damage, loss of data or poor performance may be caused, if this
requirement is ignored.
Commissioning Engineer: The engineer who installs or operates the equipment should
be well trained in electricity and safety and familiar with the operation, debug, and
maintenance of the equipment.
Warning Label
The warning label indicates the possibility of human injury or equipment damage, and
advises the proper step to avoid the danger. In this manual, there are three types of
warning labels as below.
Labels
Description
Danger
Serious human injury or even death may be caused, if this requirement
is ignored.
Warning
Human injury or equipment damage may be caused, if this requirement
is ignored.
Attention
Equipment damage, loss of data or poor performance may be caused, if
this requirement is ignored.
Safety Instruction
Danger
Performed only by commissioning engineers.
This UPS is designed for commercial and industrial
applications only, and is not intended for any use in life-support
devices or system.
