IV
1. Safety Precautions
This manual contains information concerning the installation and operation of Modular UPS.
Please carefully read this manual prior to installation.
The Modular UPS cannot be put into operation until it is commissioned by engineers approved by
the manufacturer (or its agent). Not doing so could result in personnel safety risk, equipment
malfunction and invalidation of warranty.
Safety Message Definition
Danger: Serious human injury or even death may be caused, if this requirement is
ignored.
Warning: Human injury or equipment damage may be caused, if this requirement is
ignored.
Attention: Equipment damage, loss of data or poor performance may be caused, if this
requirement is ignored.
Commissioning Engineer: The engineer who installs or operates the equipment should
be well trained in electricity and safety and familiar with the operation, debug, and
maintenance of the equipment.
Warning Label
The warning label indicates the possibility of human injury or equipment damage, and
advises the proper step to avoid the danger. In this manual, there are three types of
warning labels as below.
Labels
Description
Dan
ger
Serious human injury or even death may be caused, if this requirement is ignored.
Warn
ing
Human injury or equipment damage may be caused, if this requirement is ignored.
Atte
ntion
Equipment damage, loss of data or poor performance may be caused, if this
requirement is ignored.
