V
Safety Instruction
Danger
Performed only by commissioning engineers.
This UPS is designed for commercial and industrial applications only, and
is not intended for any use in life-support devices or system.
Warning
Read all the warning labels carefully before operation, and follow the
instructions.
When the system is running, do not touch the surface with this label, to
avoid any hurt of scald.
ESD sensitive components inside the UPS, anti-ESD measure should be
taken before handling.
Move & Install
Danger
Keep the equipment away from heat source or air outlets.
In case of fire, use dry powder extinguisher only, any liquid extinguisher
can result in electric shock.
Warning
Do not start the system if any damage or abnormal parts founded.
Contacting the UPS with wet material or hands may be subject to electric
shock.
Attentio
n
Use proper facilities to handle and install the UPS. Shielding shoes,
protective clothes and other protective facilities are necessary to avoid
injury.
During positioning, keep the UPS way from shock or vibration.
Install the UPS in proper environment, more detail in section 3.3.
Debug & Operate
Danger
Make sure the grounding cable is well connected before connecting the
power cables, the grounding cable and neutral cable must be in
accordance with the local and national codes practice.
Before moving or re-connecting the cables, make sure to cut off all the
input power sources, and wait for at least 10 minutes for internal
discharge. Use a multi-meter to measure the voltage on terminals and
ensure the voltage is lower than 36V before operation
.
Risk of Voltage Backfeed. Before working on the circuits, isolate the
Uninterruptible Power Supply (UPS), and then check for Hazardous
Voltage between all terminals including the protective earth.
Attention
The earth leakage current of load will be carried by RCCB or RCD.
Initial check and inspection should be performed after long time storing of
UPS.
