GB13
GB
OPERATING ELEMENTS
n Gas lever
The engine speed is regulated with the gas lever. In order to
mow as effectively as possible, the gas lever should be
switched to .
o Light switch (depending on the model)
Use the light switch to switch the headlights on.
p Ignition lock
To start the engine, put the ignition key into the ignition lock
and turn to the right to position "II".
As soon as the engine is running, let go of the ignition key
(ignition key returns to position "I").
To switch the engine off, put the gas lever onto ,
then turn the ignition key onto position "0".
Meaning of the symbols on the foot pedals
Left hand foot pedal: switch on cutter bar
Right hand foot pedal: Clutch
Brake
Foot pedal - left "cutter bar"
Pushing the left hand foot pedal down, switches on the
cutter bar.
It is now possible to remove the foot from the pedal, as the
pedal will remain pushed down.
Renewed pressing down of the foot pedal returns to the
starting position again.
Foot pedal - right "clutch / brake"
n If the pedal is half pushed down, the clutch is
disengaged. If the pedal is completely pushed down, the
clutch is disengaged and the disk brake of the
transmission operated.
o With the pedal completely pressed down, the pedal can
be locked in the "Brake" function by pushing the stop
lever to the left (with the heel of the shoe).
Pushing the pedal down again cancels the locking - the stop
lever returns to the original position.
Switching lever (for hydrostat drive)
Possible transmission positions:
Forward gear - infinitely adjustable
Reverse gear - infinitely adjustable
and a neutral position.
For safety reasons, the switching lever must always
be in the neutral position when engaging traction.
Switching lever (for 5-gear
transmission)
With the switching lever,
5 forward gears
1 reverse gear
and1 neutral position can be switched.
Position lever for adjustment of
cutting height
The mowing appliance is lifted or lowered with the position
lever.
Six positions are available. In order to get from a higher to a
lower position, the push button on the end of the lever must
be pushed to unlock it.
In order to reach a higher position, simply push the lever
upwards into the required position
24
29
28
30
32
33
