Check level of engine oil
Change engine oil
Clean the air filter
Replace the air filter
Check the spark plug
Check the brake
Check the tyre pressure
Check mowing blade
Check for loose parts
Check drive belt
Clean the lawn tractor
Clean air intake grille on engine
Clean grass and cuttings from transmission
For hydrostat drive:
Clean ventilator for transmission cooling
Lubrication plan Î page GB 17
Before each
use
After each use
After the first 5
hours
After 25 hours
of operation
After 50 hours
of operation
Before each
storage
)* see operating instructions of the engine manufacturer
In cases of high load and high temperatures, shorter maintenance intervals than those stated in the table may be necessary.
MAINTENANCE AND SERVICE
Maintenance, service and cleaning work may only be carried out when the machine has been turned off and has cooled down
and the ignition key has been removed.
The following tasks may be carried out by the user himself. All the other maintenance, service and upkeep tasks must be carried
out by a qualified service agent.
Mowing system
On the mowing deck, there is a connection for a ½" water
hose coupling.
The mowing system can be cleaned by connecting a water
hose.
1. Lower the mowing deck to the lowest cutting height.
2. Start the engine - set a medium engine speed.
3. Switch the mowing appliance on.
4. Connect the hose to the connection and turn the water
on.
After a few minutes, the mowing system has been
cleaned.
5. Leave the mowing system to run for a few more minutes
in order to spin the water out.
Checking by a qualified service agent is
necessary:
- after impact with an obstacle
- if the V-belt is defective
- if the engine comes to an immediate standstill
- if the brake performance drops
- if the blade is bent (do not straighten)
- if the drive belt slips
- if the blade shaft is bent (do not straighten)
- if there is a defect in the blade holder
- if there is damage to the transmission.
