This device must only be operated in an altitude between -20 and 2000 m over NN.

The ambient contamination must never exceed level 1 and must not be conducting, only dry.

Never use the device during thunderstorms. Over voltage could destroy the device. Always disconnect the

device during thunderstorms.

Operate the device only after having familiarized with its functions. Do not permit operation by persons not

qualified for operating the device. Most damages are the result of unprofessional operation!

Never use solvents or aggressive detergents in order to clean the device! Rather use a soft and damp cloth.

Please use the original packaging if the device is to be transported.

Never remove the serial barcode from the device as this would make the guarantee void.

Please consider that unauthorized modifications on the speaker system are forbidden due to safety reasons!

If this device will be operated in any way different to the one described in this manual, the product may suffer

damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-

circuit, burns, electric shock, hearing loss etc.

5. DESCRIPTION

5.1 Features

PA power amplifier

• 1 line input (optionally XLR or 6.3 mm jack)

• 1 feed-through output (optionally XLR or 6.3 mm jack)

• 70 V, 100 V or 4-16 ohms operation

• Master control

• LED indicators for power, signal, clip and fault

• Protective circuits: over load, short circuit, turn-on delay, over heating, DC offset protection

• Load detection and power control

• 19" dimensions for rack installation
