ADJ Products, LLC - www.adj.com - Vizi Hex Wash7 Instruction Manual Page 19ADJ Products, LLC - www.adj.com - Vizi Hex Wash7 Instruction Manual Page 18
Vizi Hex Wash7 21 Channel DMX Mode (Standard)
Channel Value Function
21 AUTO PROGRAMS
0 - 79 NORMAL
80 - 84 ALL MOTOR RESET
85 - 99 NO FUNCTION
101 - 119 INTERNAL PROGRAM 1
120 - 139 INTERNAL PROGRAM 2
140 - 159 INTERNAL PROGRAM 3
160 - 179 INTERNAL PROGRAM 4
180 - 199 INTERNAL PROGRAM 5
200 - 219 INTERNAL PROGRAM 6
220 - 239 INTERNAL PROGRAM 7
240 - 255 NO FUNCTION
Vizi Hex Wash7 27 Channel DMX Mode (Extend)
Channel Value Function
1 0 - 255 PAN MOVEMENT 8bit (540° or 630°)
2 0 - 255 PAN MOVEMENT FINE 16bit
3 0 - 255 TILT MOVEMENT 8bit
4 0 - 255 TILT MOVEMENT FINE 16bit
5 0 - 255 RED CENTER LED 0% - 100%
6 0 - 255 GREEN CENTER LED 0% - 100%
7 0 - 255 BLUE CENTER LED 0% - 100%
8 0 - 255 WHITE CENTER LED 0% - 100%
9 0 - 255 AMBER CENTER LED 0% - 100%
10 0 - 255 UV CENTER LED 0% - 100%
11 0 - 255 RED OUTER LED’S 0% - 100%
12 0 - 255 GREEN OUTER LED’S 0% - 100%
13 0 - 255 BLUE OUTER LED’S 0% - 100%
14 0 - 255 WHITE OUTER LED’S 0% - 100%
15 0 - 255 AMBER OUTER LED’S 0% - 100%
16 0 - 255 UV OUTER LED’S 0% - 100%
17 0 - 255 COLOR MACROS
PLEASE SEE PAGE’S 22-24
18 SHUTTER/STROBE
0 - 31 LED OFF
32 - 63 LED ON
64 - 95 STROBING SLOW - FAST
96 - 127 LED ON
128 - 159 STROBE PULSE SLOW - FAST
160 - 191 LED ON
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 LED ON
19 MASTER DIMMER
0 - 255 0% - 100%
20 DIMMER FINE
0 - 255 0% - 100%
21 FOCUS
0 - 255 NEAR - FAR
