Vizi Hex Wash7 27 Channel DMX Mode (Extend)
Channel Value Function
22 AUTO PROGRAMS
0 OFF
1 - 20 PROGRAM 1
21 - 40 PROGRAM 2
41 - 60 PROGRAM 3
61 - 80 PROGRAM 4
81 - 100 PROGRAM 5
101 - 120 PROGRAM 6
121 - 140 PROGRAM 7
141 - 160 PROGRAM 8
161 - 180 PROGRAM 9
181 - 200 PROGRAM 10
201 - 220 PROGRAM 11
221 - 240 PROGRAM 12
241 - 250 PROGRAM 13
251 - 255 PROGRAM 14
23 PROGRAM SPEED
0 - 255 SLOW - FAST
24 AUTO PROGRAM FADE
0 NORMAL
1 - 255 SLOW - FAST
25 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
26 PAN/TILT SPEED
0 - 225 FAST - SLOW
226 - 235 BLACKOUT BY MOVEMENT
236 - 255 NO FUNCTION
Vizi Hex Wash7 27 Channel DMX Mode (Extend)
Channel Value Function
27 AUTO PROGRAMS
0 - 79 NORMAL
80 - 84 ALL MOTOR RESET
85 - 99 NO FUNCTION
101 - 119 INTERNAL PROGRAM 1
120 - 139 INTERNAL PROGRAM 2
140 - 159 INTERNAL PROGRAM 3
160 - 179 INTERNAL PROGRAM 4
180 - 199 INTERNAL PROGRAM 5
200 - 219 INTERNAL PROGRAM 6
220 - 239 INTERNAL PROGRAM 7
240 - 255 NO FUNCTION
