![Boss SY-1000 [11/22] Screen operations](/views2/1990110/page11/bgb.png)
Basic Operation
11
Screen Operations
In the play screen, you can turn or press the [1]–[6] knobs to adjust
the parameters that are shown in the lower part of the display.
Operating Example 1 (INST Screen)
Press operation
Turn operation
Operation Explanation
Turn the [1] knob Changes the INST TYPE of INST1.
Press the [1] knob
Accesses a screen where you can
switch the INST TYPE variation of
INST1.
Turn the [2] knob
Turns INST1 on/o.
When o, the icon is shown in gray.
Press the [2] knob Accesses the edit screen for INST1.
MEMO
As for INST1, you can operate INST2 with the [3] knob and [4] knob,
and operate INST3 with the [5] knob and [6] knob.
Operating Example 2 (INST Edit Screen)
Press operation
Use the [6] knob to select
Use the PAGE [K] [J]
buttons to switch
Turn operation
Operation Explanation
Turn the [1]–[5] knobs
Changes the value of the setting for
the parameter
Turn the [6] knob Selects the block to edit.
Press the [6] knob
Shows a list with all parameters of
the selected block.
Press the [K] [J] (PAGE)
buttons
Switches the parameters to show.
Operating Example 3 (EFFECT Edit Screen)
Turn operation
Operation Explanation
Turn the [1]–[5] knobs
Changes the value of the setting for
the parameter
Turn the [6] knob Selects the block to edit.
Press the [6] knob Turns the selected block on/o.
Long-press the [6] knob
Shows a list with all parameters of
the selected block.
Turn the [6] knob while
pressing it
Changes the position of the selected
block.
MEMO
To change a value in larger steps, turn a [1]–[5] knob while pressing it.
