13
Editing a Patch
Here’s how to create a patch by editing the parameters of the INST
blocks and the eect block, and combining them.
Changing the INST
1. Press the [INST] button.
The INST screen appears.
2. Turn the [1]–[6] knobs.
The INST screen shows the INST TYPE for INST1–INST3.
Operation Explanation
Turn the [1] knob Changes the INST TYPE of INST1.
Press the [1] knob
Accesses a screen where you can
switch the INST TYPE variation of
INST1.
Turn the [2] knob
Turns INST1 on/o.
When o, the icon is shown in gray.
Press the [2] knob Accesses the edit screen for INST1.
MEMO
As for INST1, you can operate INST2 with the [3] knob and [4]
knob, and operate INST3 with the [5] knob and [6] knob.
Editing the INST
You can edit each INST in detail.
Here we explain using the example of the DYNAMIC SYNTH screen of
INST1.
1. In the INST screen, press the [2] knob.
The INST1 screen appears.
* The pages diers depending on the INST TYPE.
2. Turn the [6] knob to select the block that you want
to edit.
The selected block is shown in white.
3. Turn the [1]–[5] knobs to edit the setting of the
parameter.
MEMO
5 To change a value in larger steps, turn a knob while pressing it.
5 You can use the PAGE [K] [J] buttons to switch between the
parameters.
5 The number of parameters and pages diers depending on the
eect.
5 In the edit screen, you can press the [INST] button to switch to the
edit screen of another INST.
Viewing All Parameters While You Edit
You can also edit while viewing a list of all parameters for the
selected block.
1. In the edit screen, press the [6] knob.
Shows a list with all parameters of the selected block.
2. Turn the [1]–[6] knobs to edit the setting of the
parameter.
MEMO
You can use the PAGE [K] [J] buttons to switch between the
parameters.
