Editing a Patch
15
Editing the Eects
You can edit the eect settings, and change the order of blocks such
as output and send/return (the eect chain).
Basic Operation for Eect Editing
1. Press the [EFFECT] button.
The edit screen (eect chain) appears.
2. Turn the [6] knob to select the block that you want
to edit.
The selected block is enclosed by a thick frame.
* By pressing the [6] knob you can turn the selected eect on/o.
Eects that are o are shown in gray. When the eect is turned on,
it is shown in white.
O On
3. Use knobs [1]–[5] to adjust the parameters that are
shown below the screen.
Use the PAGE [K] [J] buttons to switch between the parameters
that you want to edit. The current page is indicated in the lower
center of the screen.
* To change a value in larger steps, turn a knob while pressing it.
* The number of parameters and pages diers depending on the
eect.
Editing While Viewing All Parameters
You can also edit while viewing a list of all parameters for the
selected block.
1. In the edit screen, long-press the [6] knob.
Shows a list with all parameters of the selected block.
2. Turn the [1]–[6] knobs to edit the parameter
settings.
MEMO
You can use the PAGE [K] [J] buttons to switch between the
parameters.
Use the PAGE [K] [J]
buttons to switch
Changing the Eect Order
By moving blocks such as eects, output, and send/return, you can
freely change the order in which the eects are placed, or arrange
them in parallel.
MEMO
5 You can change the order of the INST1–3 blocks and the NORMAL
block.
5 The MST (MASTER) block cannot be moved.
1. Press the [EFFECT] button.
The eect chain is shown.
2. Use the [6] knob to select the block that you want
to move.
3. While pressing the [6] knob, turn it left or right.
The selected block moves left or right.
