Main Specications
BOSS SY-1000: Guitar Synthesizer
Patch Memory
Guitar mode 200 (preset) + 200 (user)
Bass mode 200 (preset) + 200 (user)
AD Conversion
Divided pickup 32 bits + AF method
* AF method (Adaptive Focus
method) is a proprietary method
from Roland & BOSS that vastly
improves the signal-to-noise
(SN) ratio of the AD and DA
converters.
Normal pickup 32 bits + AF method
DA Conversion 32 bits
Sample Rate 48 kHz
Normal Input Level
GUITAR INPUT -10 dBu
RETURN -10 dBu
Maximum Input Level
GUITAR INPUT +16 dBu
RETURN +8 dBu
Input Impedance
GUITAR INPUT 1 MΩ
RETURN 1 MΩ
Normal Output Level
MAIN OUTPUT (L/PHONES, R/MONO) -10 dBu
SUB OUTPUT (L, R/MONO) -10 dBu
SEND -10 dBu
Output Impedance
MAIN OUTPUT (L/PHONES, R/MONO) 44 Ω
SUB OUTPUT (L, R/MONO) 1 kΩ
SEND 1 kΩ
Recommended Load
Impedance
MAIN OUTPUT (L/PHONES, R/MONO)
10 kΩ or greater (when using headphones: 44 Ω or
greater)
SUB OUTPUT (L, R/MONO) 10 kΩ or greater
SEND 10 kΩ or greater
Display Graphic LCD (512 x 160 dots, backlit LCD)
Connectors
GK IN connector 13-pin DIN type
GUITAR INPUT jack, SEND jack, RETURN jack, MAIN
OUTPUT (L/PHONES, R/MONO) jacks, SUB OUTPUT
(L, R/MONO) jacks
1/4-inch phone type
CTL3, 4/EXP1 jack, CTL5, 6/EXP2 jack 1/4-inch TRS phone type
USB COMPUTER port
USB B type (supports High-Speed USB, USB Audio, and
USB MIDI)
MIDI (IN, OUT/THRU) connectors
DC IN jack
Power Supply AC adaptor
Current Draw 800 mA
Dimensions
345 (W) x 245 (D) x 67 (H) mm
13-5/8 (W) x 9-11/16 (D) x 2-11/16 (H) inches
Weight (excluding AC
adaptor)
2.5 kg
5 lbs 9 oz
Accessories
AC Adaptor
Owner’s Manual
Leaet “USING THE UNIT SAFELY”
Options
(sold separately)
Divided pickup: GK-3 (for guitar), GK-3B (for bass guitar)
GK cable: GKC-5 (5 m, 15 feet), GKC-10 (10 m, 30 feet)
Footswitch: FS-5U, FS-5L, FS-6, FS-7
Expression Pedal: EV-30, FV-500L, FV-500H, Roland EV-5
Unit selector: Roland US-20
* 0 dBu = 0.775 Vrms
* This document explains the specications of the product at the time that the document was issued. For the latest information, refer to the Roland
website.
